Toyota Yaris Cross
2020-08 → present · chassis MXPB1#,MXPJ1# · catalogue 541110 · Japan
Supported model
Data version 2024-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86510A — Horn Assy, Security | ||||
| 86560-K0020 |
Horn Assy, Security
2020-08 → 2024-01
ended
|
MXPJ1# | ¥2,190 | |
| 86560-K0020 |
Horn Assy, Security
2024-01 → —
|
MXPJ1# | ¥2,190 | |
| 86520 — Horn Assy, Low Pitched | ||||
| 86520-52230 |
Horn Assy, Low Pitched
2023-01 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥2,190 | |
| 86520-68010 |
Horn Assy, Low Pitched
2020-08 → 2023-01
ended
|
MXPB1#,MXPJ1# | ¥2,410 | |
| 86520-52250 |
Horn Assy, Low Pitched
2024-01 → —
|
MXPB1#,MXPJ1# | ¥2,190 | |
| 86570 — Speaker Assy, Vehicle Approaching | ||||
| 86570-K0010 |
Speaker Assy, Vehicle Approaching
2020-08 → 2024-01
ended
|
MXPJ1# | — | |
| 86570-K0010 |
Speaker Assy, Vehicle Approaching
2024-01 → —
|
MXPJ1# | — | |
| 86572 — Controller, Vehicle Approaching Speaker | ||||
| 86572-52160 |
Controller, Vehicle Approaching Speaker
2020-08 → 2024-01
ended
|
MXPJ1# HBDG,HBDX,HBDZ | — | |
| 86572-52200 |
Controller, Vehicle Approaching Speaker
2022-08 → 2024-01
ended
|
MXPJ10 GRS | — | |
| 865H2-52030 |
Controller, Vehicle Approaching Speaker
2024-01 → —
|
MXPJ1# HBDG,HBDX,HBDZ,U | ¥8,800 | |
| 865H2-52040 |
Controller, Vehicle Approaching Speaker
2024-01 → —
|
MXPJ10 GRS | ¥8,800 | |
| 86591 — Bracket, Horn | ||||
| 86591-52080 |
Bracket, Horn
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥380 | |
| 86591-52080 |
Bracket, Horn
2024-01 → —
|
MXPB1#,MXPJ1# | ¥380 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
