Toyota Yaris Cross
2020-08 → present · chassis MXPB1#,MXPJ1# · catalogue 541110 · Japan
Supported model
Data version 2024-01
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86466D — Cover, Forward Recognition, NO.1 | ||||
| 86466-52100 note |
Cover, Forward Recognition, NO.1
2022-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥3,130 | |
| 86466-K0010 note |
Cover, Forward Recognition, NO.1
2020-08 → 2021-08
ended
|
MXPB1#,MXPJ1# HBDX,X | ¥2,560 | |
| 86466-K0010 |
Cover, Forward Recognition, NO.1
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥2,560 | |
| 86466-52180 note |
Cover, Forward Recognition, NO.1
2025-01 → 2025-03
ended
|
MXPB1#,MXPJ1# HBDX,X | ¥3,620 | |
| 86466-52180 note |
Cover, Forward Recognition, NO.1
2025-01 → —
|
MXPB1#,MXPJ1# G,GRS,HBDG,HBDZ,Z | ¥3,620 | |
| 86466-52200 |
Cover, Forward Recognition, NO.1
2024-01 → —
|
MXPB1#,MXPJ1# | ¥2,870 | |
| 86466E — Cover, Forward Recognition, NO.2 | ||||
| 86466-K0020 note |
Cover, Forward Recognition, NO.2
2020-08 → 2021-08
ended
|
MXPB1#,MXPJ1# HBDX,X | ¥630 | |
| 86466-K0020 |
Cover, Forward Recognition, NO.2
2020-08 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥630 | |
| 86467-52080 |
Cover, Forward Recognition, NO.2
2024-01 → —
|
MXPB1#,MXPJ1# | ¥750 | |
| 8646C — Camera, Forward Recognition | ||||
| 8646C-0D010 note |
Camera, Forward Recognition
2020-08 → 2021-02
ended
|
MXPB1#,MXPJ1# | ¥47,300 | |
| 8646C-0D010 note |
Camera, Forward Recognition
2020-08 → 2021-03
ended
|
MXPB1#,MXPJ1# HBDX,X | ¥47,300 | |
| 8646C-52050 note |
Camera, Forward Recognition
2021-03 → 2021-08
ended
|
MXPB1#,MXPJ1# HBDX,X | ¥47,300 | |
| 8646C-52050 note |
Camera, Forward Recognition
2021-03 → 2024-01
ended
|
MXPB1#,MXPJ1# | ¥47,300 | |
| 8646C-52290 |
Camera, Forward Recognition
2024-01 → —
|
MXPB1#,MXPJ1# | ¥43,000 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
