Toyota Lexus RZ300E/450E
2023-02 → present · chassis XEBM1# · catalogue 564110 · Japan
Supported model
Data version 2023-11
Side Moulding
88 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 62505E | Cover Sub-assy, Quarter Pillar, RH |
| 62506C | Cover Sub-assy, Quarter Pillar, LH |
| 67863F | Weatherstrip, Front Door, NO.2 RH |
| 67864F | Weatherstrip, Front Door, NO.2 LH |
| 67897N | Weatherstrip, Rear Door, NO.4 RH |
| 67897P | Weatherstrip, Rear Door, NO.4 LH |
| 75061 | Moulding Set, Outside |
| 75062 | Moulding Set, Outside, LH |
| 75073 | Moulding Sub-assy, Front Door, Outside Lower RH |
| 75074 | Moulding Sub-assy, Front Door, Outside Lower LH |
| 75075 | Moulding Sub-assy, Rear Door, Outside RH |
| 75076 | Moulding Sub-assy, Rear Door, Outside LH |
| 75077 | Moulding Sub-assy, Rear Door Outside Lower RH |
| 75078 | Moulding Sub-assy, Rear Door Outside Lower LH |
| 75085E | Screw, NO.1 |
| 75392A | Retainer, Outside Moulding, NO.1 |
| 75392F | Retainer, Outside Moulding |
| 75392G | Retainer, Outside Moulding, NO.1 |
| 75393A | Retainer, Outside Moulding, NO.2 RH |
| 75394D | Retainer, Outside Moulding, NO.2 LH |
| 75396 | Clip, Outside Moulding, NO.2 |
| 75396D | Clip, Outside Moulding, NO.2 |
| 75553A | Moulding, Roof Drip Side Finish, Rear RH |
| 75554A | Moulding, Roof Drip Side Finish, Rear LH |
| 75555D | Moulding, Roof Drip Side Finish, Center RH |
| 75556C | Moulding, Roof Drip Side Finish, Center LH |
| 75561A | Clip, Roof Drip Side Finish Moulding |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75601C | Clip, Front Fender Moulding |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75605B | Moulding Sub-assy, Quarter Outside, RH |
| 75606B | Moulding Sub-assy, Quarter Outside, LH |
| 75611C | Moulding, Front Fender, Outside RH |
| 75612C | Moulding, Front Fender, Outside LH |
| 75615C | Moulding, Front Fender, Rear RH |
| 75616C | Moulding, Front Fender, Rear LH |
| 75617C | Moulding, Front Fender, Lower Rear RH |
| 75618C | Moulding, Front Fender, Lower Rear LH |
| 75653A | Moulding, Quarter, Outside Rear RH |
| 75654A | Moulding, Quarter, Outside Rear LH |
| 75657A | Moulding, Quarter Panel, Lower Rear RH |
| 75658A | Moulding, Quarter Panel, Lower Rear LH |
| 75687D | Protector, Outside Moulding, Rear |
| 75696C | Pad, Body Outside Moulding, NO.1 |
| 75710 | Moulding Assy, Front Door Belt, RH |
| 75720 | Moulding Assy, Front Door Belt, LH |
| 75730 | Moulding Assy, Rear Door Belt, RH |
| 75740 | Moulding Assy, Rear Door Belt, LH |
| 75753 | Moulding, Front Door Window Frame, Upper RH |
| 75754A | Moulding, Front Door Window Frame, Upper LH |
| 75755C | Moulding, Front Door Window Frame, Rear RH |
| 75756D | Moulding, Front Door Window Frame, LH(CENTER PILLAR SIDE) |
| 75763A | Moulding, Rear Door Window Frame, Upper RH |
| 75764A | Moulding, Rear Door Window Frame, Upper LH |
| 75765B | Moulding, Rear Door Window Frame, RH(REAR PILLAR SIDE) |
| 75766B | Moulding, Rear Door Window Frame, LH(REAR PILLAR SIDE) |
| 75792 | Clip, Door Window Frame Moulding |
| 75850A | Moulding Assy, Body Rocker Panel, RH |
| 75851F | Grommet(FOR BODY ROCKER PANEL MOULDING) |
| 75857A | Cover, Rocker Panel Moulding, RH |
| 75860A | Moulding Assy, Body Rocker Panel, LH |
| 75867C | Clip, Rocker Panel Moulding |
| 75873B | Moulding, Quarter Wheel Opening, RH |
| 75874A | Moulding, Quarter Wheel Opening, LH |
| 75879 | Retainer, Quarter Opening |
| 75881B | Joint, Outside Moulding |
| 75885A | Tape, Moulding, NO.6 |
| 75895A | Tape, Moulding, NO.1 |
| 75895C | Tape, Moulding, NO.3 |
| 75895S | Tape, Moulding, NO.1 |
| 75896A | Tape, Moulding, NO.2 |
| 75896C | Tape, Moulding, NO.2 |
| 75897A | Tape, Moulding, NO.2 |
| 75897B | Tape, Moulding, NO.3 |
| 75898A | Tape, Moulding, NO.4 |
| 75898C | Tape, Moulding, NO.4 |
| 75899A | Tape, Moulding, NO.5 |
| 75899B | Tape, Front Fender Moulding, NO.7 |
| 76901B | Mudguard Sub-assy, Fender Panel, RH |
| 76901C | Clip, Fender Panel Mudguard |
| 76902B | Mudguard Sub-assy, Fender Panel, LH |
| 76923B | Retainer, Side Mudguard |
| 76924G | Retainer, Rocker Panel Moulding |
| 76924H | Retainer, Side Mudguard, NO.2 |
| 76931B | Bracket, Side Mudguard, NO.1 RH |
| 76932B | Bracket, Side Mudguard, NO.1 LH |
| 76935A | Bracket, Side Mudguard, NO.3 RH |
| 76936 | Bracket, Side Mudguard, NO.3 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
