Toyota Pixis Mega
2015-07 → present · chassis LA700A,LA710A · catalogue 591110 · Japan
Supported model
Data version 2018-01
Deck Board & Deck Trim Cover
28 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 58400 | Belt Assy, Luggage Hold, NO.1 |
| 58401E | Board Sub-assy, Deck |
| 58401J | Clip(FOR DECK BOAD) |
| 58410B | Board Assy, Deck |
| 58416D | Clip, Rear Floor Board |
| 58418 | Bracket, Deck Board, NO.1 |
| 58427C | Spacer, Rear Floor Board |
| 58449 | Clip, Deck Board |
| 58492B | Hook, Deck Board Lock |
| 58540H | Mat Assy, Floor, Rear |
| 58582D | Mat, Rear Floor, Rear |
| 62521C | Cover, Quarter Trim RH |
| 62522B | Cover, Quarter Trim LH |
| 62594F | Pocket, Quarter Trim, RH |
| 62595G | Pocket, Quarter Trim, LH |
| 62630U | Panel Assy, Quarter Trim, Rear RH |
| 62640S | Panel Assy, Quarter Trim, Rear LH |
| 64045 | Leg Sub-assy, Luggage Room Table, RH |
| 64421A | Tray, Luggage Compartment |
| 64716D | Cover, Deck Trim, Rear |
| 64718A | Cover, Deck Trim Service Hole |
| 64718D | Cover, Deck Trim Service Hole |
| 64726B | Clip, Deck Rear Trim |
| 64750E | Carpet Sub-assy, Deck Trim Side, RH |
| 64760B | Carpet Sub-assy, Deck Trim Side, LH |
| 66310H | Hook Assy, Rope |
| 66311 | Hook, Rope |
| 67935E | Retainer, Door Trim |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
