Toyota Pixis Joy

2016-09 → present · chassis LA250,260 · catalogue 592110 · Japan

Supported model Data version 2017-10

Front Door Panel & Glass

37 part groups · 2 illustrations

PNC	Description
67001	Panel Sub-assy, Front Door, RH
67001A	Cushion, Front Door Panel
67002	Panel Sub-assy, Front Door, LH
67216D	Stopper, Front Door Glass, Upper NO.2
67403F	Frame Sub-assy, Front Door, Rear Lower RH
67404F	Frame Sub-assy, Front Door, Rear Lower LH
67491A	Garnish, Front Door Lower Frame Bracket, RH
67492A	Garnish, Front Door Lower Frame Bracket, LH
67601	Board Sub-assy, Front Door Trim, RH
67601A	Retainer(FOR FRONT DOOR TRIM BOARD)
67601M	Retainer, Door Trim, NO.2
67602	Board Sub-assy, Front Door Trim, LH
67831	Cover, Front Door Service Hole, RH
67832	Cover, Front Door Service Hole, LH
67837A	Seal, Front Door Vent, RH
67838A	Seal, Front Door Vent, LH
67861	Weatherstrip, Front Door, RH
67862	Weatherstrip, Front Door, LH
67867C	Retainer, Front Door Weatherstrip, RH
67868C	Retainer, Front Door Weatherstrip, LH
67869B	Clip, Front Door Weatherstrip
67869E	Clip, Front Door Weatherstrip
68101	Glass Sub-assy, Front Door, RH
68102	Glass Sub-assy, Front Door, LH
68141C	Run, Front Door Glass, RH
68141E	Run, Front Door Glass, RH
68147F	Stop, Front Door Glass, Upper
68151C	Run, Front Door Glass, LH
68151D	Run, Front Door Glass, LH
68160C	Weatherstrip Assy, Front Door Glass, Outer RH
68171B	Weatherstrip, Front Door Glass, Inner RH
68172A	Weatherstrip, Front Door Glass, Inner LH
68210C	Weatherstrip Assy, Front Door Glass, Outer LH
68610B	Check Assy, Front Door, RH
68620	Check Assy, Front Door, LH
75955B	Tape, Black Out Front Door, Outer Upper RH
75956B	Tape, Black Out Front Door, Outer Upper LH

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
