Toyota Pixis Epoch

2017-05 → present · chassis LA350A,LA360A · catalogue 594120 · Japan

Supported model Data version 2018-05

Switch & Relay & Computer

47 part groups · 7 illustrations

PNC	Description
28850	Sensor Assy, Battery Current
74468A	Bracket, Relay Block
82600	Block Assy, Fuse
82616	Puller, Fuse
82641	Relay, Integration NO.1
82661	Cover, Relay Block, NO.1
83320	Gage Assy, Fuel Sender
83530	Switch Assy, Oil Pressure (FOR ENGINE)
83650	Fusee
84140	Switch Assy, Headlamp Dimmer
84152	Switch, Headlamp Leveling
84231A	Switch, Courtesy Lamp
84231B	Switch, Courtesy Lamp
84231C	Switch, Courtesy Lamp
84235A	Switch, Courtesy Lamp
84330	Switch Assy, Hazard Warning Signal
84340	Switch Assy, Stop Lamp
84345	Adjuster, Stop Lamp Switch Mounting
84380	Switch Assy, Brake Warning Test
84450	Switch Assy, Ignition OR Starter
84540	Switch Assy, Neutral Start
84650	Switch Assy, Windshield Wiper
84751F	Switch, Seat Heater
84751G	Switch, Seat Heater
84790	Switch Assy, Rear Window Defogger
84810	Switch Assy, Power Window Regulator
84810D	Switch Assy, Power Window Regulator, Rear
84810G	Switch Assy, Power Window Regulator, Rear NO.2
84820	Master Switch Assy, Power Window Regulator
84840G	Switch Assy, Back Door Opener
84870A	Switch Assy, Outer Mirror
84941A	Base, Switch
84970	Switch Assy, Combination
85530	Socket Assy, Power Outlet, NO.1
85535E	Cover, Power Outlet Socket, NO.2
85912D	Relay
85916D	Relay, Fog Lamp
86450B	Switch Assy, Corner Control
89421B	Sensor, Vacuum
89422A	Sensor, Water Temperature
89439	Bracket, Sensor
89465	Sensor, Oxygen
89465A	Sensor, Oxygen NO.2
89611	Switch, Push Start
89615	Sensor, Knock Control
89650	Computer Assy, Power Steering
89953	Sensor, Belt Warning Occupant Detection

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
