Toyota Copen
2019-10 → present · chassis LA400A · catalogue 595110 · Japan
Supported model
Data version 2019-10
Switch & Relay & Computer
62 part groups · 7 illustrations
Part groups
| PNC | Description |
|---|---|
| 28300E | Relay Assy, Starter, NO.1 |
| 28371 | Relay, Ignition, NO.1 |
| 28850 | Sensor Assy, Battery Current |
| 82600 | Block Assy, Fuse |
| 82616 | Puller, Fuse |
| 82661 | Cover, Relay Block, NO.1 |
| 82760 | Bracket Assy, Relay Block |
| 83150C | Indicator Assy |
| 83320 | Gage Assy, Fuel Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 83950M | Lamp Assy, Telltale |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84210 | Switch Assy, Back-up Lamp |
| 84210B | Gasket, Back-up Lamp Switch |
| 84231A | Switch, Courtesy Lamp |
| 84231B | Switch, Courtesy Lamp |
| 84250A | Switch Assy, Steering Pad |
| 84290 | Switch Assy, Limit |
| 84306 | Cable Sub-assy, Spiral |
| 84317 | Sensor, Steering Position |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84380 | Switch Assy, Brake Warning Test |
| 84470A | Switch Assy, Ecorun Cancel |
| 84490H | Switch Assy, Corner Pole Sensor |
| 84520 | Switch Assy, Clutch Start |
| 84535A | Switch, Door Lock |
| 84540 | Switch Assy, Neutral Start |
| 84650 | Switch Assy, Windshield Wiper |
| 84722F | Switch, Transmission Control |
| 84751F | Switch, Seat Heater |
| 84810 | Switch Assy, Power Window Regulator |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84821 | Switch, Power Window Lock |
| 84840 | Switch Assy, Luggage Compartment Door Opening |
| 84860A | Switch Assy, Sliding Roof |
| 84870A | Switch Assy, Outer Mirror |
| 84970 | Switch Assy, Combination |
| 84988F | Switch, Traction Control |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85535E | Cover, Power Outlet Socket, NO.2 |
| 85913C | Relay, Heater, NO.1 |
| 85916D | Relay, Fog Lamp |
| 85916P | Relay, Headlamp |
| 85925 | Relay, Radiator Fan |
| 85933 | Computer, Shift Lock Control |
| 85934 | Relay, Magnet-clutch |
| 85934D | Computer Assy, Power Window |
| 86230D | Controller Assy, Stereo Component |
| 86530A | Relay, Horn |
| 86830A | Accessory Socket & Cover Assy |
| 89421B | Sensor, Vacuum |
| 89422A | Sensor, Water Temperature |
| 89465 | Sensor, Oxygen |
| 89465A | Sensor, Oxygen NO.2 |
| 89530C | Computer Assy, Transmission Control |
| 89611 | Switch, Push Start |
| 89615 | Sensor, Knock Control |
| 89650 | Computer Assy, Power Steering |
| 89720 | Computer Assy, Sliding Roof Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
