Toyota Pixis Space

2011-09 → 2016-12 · chassis L575A,L585A · catalogue 597110 · Japan

Supported model Data version 2016-12
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Exhaust Pipe

10 part groups · 3 illustrations

Illustrations

Figure 17C9CE 17C9CE 2011-09 → — Figure 17C9CF 17C9CF 2011-09 → 2016-01 Figure 17C9CG 17C9CG 2016-01 → —

Part groups

PNCDescription
17410 Pipe Assy, Exhaust, Front
17410B Gasket, Exhaust Pipe
17410K Spring, Exhaust Pipe
1741A Pipe Set, Exhaust
17420Y Pipe Set, Exhaust, Front
17430 Pipe Assy, Exhaust, Tail
17430X Pipe Set, Exhaust Tail
17451 Gasket, Exhaust Pipe
17567A Cushion, Exhaust Pipe Support, NO.2
17569C Bolt, Exhaust Pipe Support
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
