Toyota Pixis Space
2011-09 → 2016-12 · chassis L575A,L585A · catalogue 597110 · Japan
Supported model
Data version 2016-12
Instrument Panel & Glove Compartment
44 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 51960B | Hook Assy, Front |
| 55041B | Door Sub-assy, Instrument Panel Box, NO.1 |
| 55061 | Register Sub-assy, Instrument Panel, NO.1 |
| 55217B | Retainer, Dash Panel Silencer |
| 55301 | Panel Sub-assy, Instrument |
| 55305 | Box Sub-assy, Instrument Panel, Center |
| 55308D | Box Sub-assy, Instrument Panel, Center |
| 55314A | Panel, Instrument, Lower Center |
| 55331 | Reinforcement, Instrument Panel |
| 55349A | Cushion, Instrument Panel |
| 55359B | Box, Instrument Panel, Center |
| 55394B | Bolt, Instrument Panel |
| 55395A | Retainer, Instrument Panel Clamp |
| 55404C | Panel Sub-assy, Instrument Cluster Finish, NO.2 |
| 55406B | Panel Sub-assy, Instrument Cluster Finish, Lower Center |
| 55406D | Clip(FOR PANEL, INSTRUMENT CLUSTER FINISH) |
| 55422C | Panel, Instrument Cluster Finish, Center Upper |
| 55431B | Panel, Instrument Panel Finish, Upper |
| 55432B | Panel, Instrument Panel Finish, Lower |
| 55435A | Panel, Instrument Panel Finish, End RH |
| 55436A | Panel, Instrument Panel Finish, End LH |
| 55444C | Spring, Instrument Panel Box |
| 55445J | Spring, Instrument Panel Box |
| 55460C | Lock Assy, Instrument Panel Box |
| 55460D | Lock Assy, Instrument Panel Box |
| 55474C | Garnish, Instrument Cluster Finish Panel, NO.1 |
| 55475A | Garnish, Instrument Cluster Finish Panel, NO.2 |
| 55476A | Garnish, Instrument Cluster Finish Panel, NO.3 |
| 55510 | Door Assy, Glove Compartment |
| 55539 | Cover, Spare Switch Hole |
| 55539F | Cover, Spare Switch Hole |
| 55539G | Cover, Spare Switch Hole |
| 55539H | Cover, Spare Switch Hole |
| 55557A | Cushion, Glove Compartment Door Check |
| 55560A | Lock Assy, Glove Compartment Door |
| 55561A | Striker, Glove Compartment Door Lock |
| 55604A | Holder Sub-assy, Instrument Panel Cup |
| 55604B | Holder Sub-assy, Instrument Panel Cup |
| 55606 | Cover Sub-assy, Instrument Panel Under, NO.1 |
| 55625D | Tray, Instrument Panel Cup Holder |
| 55650 | Register Assy, Instrument Panel, NO.1 |
| 55682 | Spring, Instrument Panel Register Support |
| 73970A | Airbag Assy, Instrument Panel Passenger |
| 88376D | Cap, Blind |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
