Toyota Pixis Space
2011-09 → 2016-12 · chassis L575A,L585A · catalogue 597110 · Japan
Supported model
Data version 2016-12
Switch & Relay & Computer
54 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 28300E | Relay Assy, Starter, NO.1 |
| 28300F | Relay Assy, Starter, NO.2 |
| 28371 | Relay, Ignition, NO.1 |
| 28850 | Sensor Assy, Battery Current |
| 74468A | Bracket, Relay Block |
| 82600 | Block Assy, Fuse |
| 82616 | Puller, Fuse |
| 82661 | Cover, Relay Block, NO.1 |
| 83320 | Gage Assy, Fuel Sender |
| 83390 | Switch Assy, Vacuum Warning |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84119G | Blub |
| 84119H | Blub, NO.1 |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84152 | Switch, Headlamp Leveling |
| 84231A | Switch, Courtesy Lamp |
| 84231B | Switch, Courtesy Lamp |
| 84231C | Switch, Courtesy Lamp |
| 84235A | Switch, Courtesy Lamp |
| 84306 | Cable Sub-assy, Spiral |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330B | Bulb, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84380 | Switch Assy, Brake Warning Test |
| 84450 | Switch Assy, Ignition OR Starter |
| 84470 | Switch Assy, Warning Canceling |
| 84540 | Switch Assy, Neutral Start |
| 84650D | Switch Assy, Windshield Wiper (W/RELAY, WIPER CONTROL) |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 84810 | Switch Assy, Power Window Regulator |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84870A | Switch Assy, Outer Mirror |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85535E | Cover, Power Outlet Socket, NO.2 |
| 85900E | Relay, Idle Stop |
| 85912D | Relay |
| 85913C | Relay, Heater, NO.1 |
| 85916D | Relay, Fog Lamp |
| 85916P | Relay, Headlamp |
| 85927 | Relay, Cooling Fan |
| 85934 | Relay, Magnet-clutch |
| 86530A | Relay, Horn |
| 86830A | Accessory Socket & Cover Assy |
| 89422A | Sensor, Water Temperature |
| 89439 | Bracket, Sensor |
| 89465 | Sensor, Oxygen |
| 89465A | Sensor, Oxygen NO.2 |
| 89530C | Computer Assy, Transmission Control |
| 89615 | Sensor, Knock Control |
| 89650 | Computer Assy, Power Steering |
| 89960 | Computer Assy, Headlamp Leveling |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
