Toyota Liteace Van,Wagon
1988-08 → 1992-01 · chassis KM3#,YM3#,40,CM3#,4# · catalogue 631140 · Japan
Discontinued model
Data version 1992-09
Side Member
100 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 53829A | Protector, Front Fender, Lower |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61027A | Pillar Sub-assy, Front Body, Outer RH |
| 61028A | Pillar Sub-assy, Front Body, Outer LH |
| 61031B | Extension Sub-assy, Quarter Panel, RH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61213B | Rail, Roof Side, Outer NO.2 RH |
| 61214B | Rail, Roof Side, Outer NO.2 LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61233A | Rail, Roof Side, Inner NO.2 RH |
| 61234A | Rail, Roof Side, Inner NO.2 LH |
| 61263B | Channel, Roof Drip Side, Front RH |
| 61264A | Channel, Roof Drip Side, Front LH |
| 61267A | Channel, Roof Drip Side, Rear RH |
| 61268 | Channel, Roof Drip Side, Rear LH |
| 61301C | Pillar Sub-assy, Center Body, Outer RH |
| 61302C | Pillar Sub-assy, Center Body, Outer LH |
| 61307 | Pillar Sub-assy, Center Body, Inner RH |
| 61308 | Pillar Sub-assy, Center Body, Inner LH |
| 61339B | Seal, Center Body Pillar, Inner NO.1 |
| 61351 | Cover, Center Body, Inner RH |
| 61352 | Cover, Center Body, Inner, LH |
| 61353 | Cover, Center Pillar Upper |
| 61371 | Rail, NO.1 Center Inner, RH |
| 61372A | Rail, NO.2 Center, Inner RH |
| 61382A | Rail, NO.2 Center, Inner LH |
| 61411D | Panel, Fender, Outer RH |
| 61412D | Panel, Fender, Outer LH |
| 61421A | Panel, Fender, Inner RH |
| 61422A | Panel, Fender, Inner LH |
| 61423A | Panel, Fender, Inner Lower RH |
| 61424A | Panel, Fender, Inner Lower LH |
| 61511 | Pillar, Quarter Lock, RH |
| 61512 | Pillar, Quarter Lock, LH |
| 61605C | Panel Sub-assy, Quater, Rear Inner RH |
| 61606 | Frame Sub-assy, Back Door Opening Side, RH |
| 61606C | Panel Sub-assy, Quater, Rear Inner LH |
| 61607 | Frame Sub-assy, Back Door Opening Side, LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61619D | Reinforcement, Quarter Panel, RH |
| 61623E | Extension, Quarter Inner Panel, Rear RH |
| 61624E | Extension, Quarter Inner Panel, Rear LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61633A | Panel, Quarter Wheel House, Inner RH |
| 61634A | Panel, Quarter Wheel House, Inner LH |
| 61643 | Gusset, Quarter Wheel House Center, RH |
| 61644 | Gusset, Quarter Wheel House, Center LH |
| 61647C | Reinforcement, Wheel House, RH |
| 61648C | Reinforcement, Wheel House, LH |
| 61662A | Plate, Quarter Panel Outer Extension, Lower Rear |
| 61673B | Reinforcement, Quarter Wheel House, Inner RH |
| 61674B | Reinforcement, Quarter Wheel House, Inner LH |
| 61675C | Reinforcement, Quarter Wheel House, Inner Rear RH |
| 61676C | Reinforcement, Quarter Wheel House, Inner Rear LH |
| 61703G | Panel Sub-assy, Quarter, Inner RH |
| 61753B | Film, Quarter Inner Panel, NO.1 |
| 61754A | Film, Quarter Inner Panel, NO.2 |
| 61755B | Film, Quarter Inner Panel, NO.3 |
| 61899A | Dustproof, Quarter Panel |
| 61995 | Dam, Front Body Pillar, Outer |
| 75396A | Clip, Outside Moulding, NO.2 |
| 75396B | Clip, Outside Moulding, NO.2 |
| 75396C | Clip, Outside Moulding, NO.2 Rear |
| 76603 | Mudguard Sub-assy, Front Fender, RH |
| 76604 | Mudguard Sub-assy, Front Fender, LH |
| 76607 | Mudguard Sub-assy, Quarter Panel, Rear RH |
| 76608 | Mudguard Sub-assy, Quarter Panel, Rear LH |
| 76621C | Mudguad, Front Fender, RH |
| 76622C | Mudguard, Front Fender, LH |
| 76623B | Mudguard, Front Fender, Upper RH |
| 76624B | Mudguard, Front Fender, Upper LH |
| 76625C | Mudguad, Quarter Panel, Rear RH |
| 76626C | Mudguad, Quarter Panel, Rear LH |
| 76628B | Mudguard, Quarter Panel, Upper Rear RH |
| 76629B | Mudguard, Quarter Panel, Upper Rear LH |
| 76630F | Mudguard Assy, Front RH |
| 76640F | Mudguard Assy, Front LH |
| 76647 | Retainer, Quarter Panel Rear Mudguard |
| 76647C | Retainer, Quarter Panel Rear Mudguard |
| 76650F | Mudguard Assy, Rear RH |
| 76660F | Mudguard Assy, Rear LH |
| 76901 | Mudguard Sub-assy, Side, RH |
| 76902 | Mudguard Sub-assy, Side, LH |
| 76903 | Retainer Sub-assy, Side Mudguard |
| 76904 | Mudguard Sub-assy, Side, NO.2 |
| 76917A | Protecter, Front Mudguard, RH |
| 76918A | Protecter, Front Mudguard, LH |
| 76922E | Protector, Side Mudguard, NO.2 |
| 76924 | Retainer, Side Mudguard, NO.2 |
| 76924A | Retainer, Side Mudguard, NO.2 |
| 76924B | Retainer, Side Mudguard, NO.2 |
| 76925 | Protector, Side Mudguard, RH |
| 76926 | Protector, Side Mudguard, LH |
| 76927 | Protecter, Rear Mudguard, RH |
| 76928 | Protecter, Rear Mudguard, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
