Toyota Lite/Townace Truck
1986-10 → 1999-06 · chassis CM5#,6#,KM5#,YM55,6# · catalogue 641110 · Japan
Discontinued model
Data version 1999-12
Caution Plate
20 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 36369 | Label, Transfer Information |
| 36369A | Label, Transfer Information, NO.2 |
| 74517 | Plate, Exhaust Temperature Caution |
| 74525C | Plate, Dump Manual Caution |
| 74535C | Label, Top Cover Caution |
| 74535D | Label, Side Tarpaulin Notice |
| 74536B | Label, Top Cover Information |
| 74537C | Plate, Dump Lever |
| 74542 | Plate, Rear Window Mark |
| 74544D | Plate, Tire Carrier Caution |
| 74548A | Label, Crane Caution |
| 74552 | Plate, Safety Caution |
| 74558A | Label, Boom Turn Pivot Clamp |
| 74559A | Plate, Fuel Caution |
| 74562 | Plate, Emission Control System Information |
| 74563 | Plate, Emission Control Device Identification |
| 74571 | Plate, Brake Fluid Caution |
| 74579 | Plate, Unleaded Fuel Caution |
| 74751 | Label, Tire Pressure Information |
| 75341B | Plate, Hood Name |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
