Toyota Lite/Townace
2008-01 → present · chassis S402#,S403#,S412#,S413# · catalogue 641130 · Japan
Discontinued model
Data version 2020-10
Heating & Air Conditioning - Cooler Unit
31 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 87010 | Unit Assy, Air Conditioner |
| 87030 | Blower Assy, Air Conditioner |
| 87107A | Unit Sub-assy, Heater Radiator |
| 87111B | Case, Heater |
| 87114B | Cover, Heater |
| 87124D | Clamp, Heater, NO.3 |
| 87138C | Resistor, Blower |
| 87296B | Lever, Heater Air Damper Control |
| 87296D | Lever, Heater Air Damper Control, NO.2 |
| 87296E | Lever, Heater Air Damper Control, NO.3 |
| 87311 | Case, Heater, NO.1 |
| 87312A | Case, Heater,NO.2 |
| 87498C | Door, Air Mix |
| 88482A | Cover |
| 88501 | Evaporator Sub-assy, Cooler, NO.1 |
| 88515 | Valve, Cooler Expansion |
| 88515F | Bolt(FOR COOLER EXPANSION VALVE) |
| 88522C | Door, Air Inlet |
| 88522D | Door, Mode |
| 88539J | Hose, Drain Cooler |
| 88550B | Motor Assy, Blower |
| 88568G | Filter, Air |
| 88569F | Clamp |
| 88578W | Packing, Cooling Unit, NO.4 |
| 88579C | Packing, Cooling Unit, NO.5 |
| 88625 | Thermistor, Cooler, NO.1 |
| 88710F | Ring, O |
| 88716V | Ring, O(FOR COOLER UNIT) |
| 88897L | Grommet (FOR DRAIN HOSE) |
| 88899K | Plate, Cover |
| 88899P | Plate, Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
