Toyota Town/Masterace V,WG
1976-10 → 1982-10 · chassis KR1#,RR1#,2#,TR1# · catalogue 651110 · Japan
Discontinued model
Data version 1983-03
Control Shaft & Crossshaft
68 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 33501 | Shaft Sub-assy, Control (FOR COLUMN SHIFT) |
| 33503 | Lever Sub-assy, Shift(FOR COLUMN SHIFT) |
| 33504 | Knob Sub-assy, Shift Lever (FOR COLUMN SHIFT) |
| 33505 | Seal Sub-assy, Control Shaft Dust (FOR COLUMN SHIFT) |
| 33513 | Shaft, Control Shaft Bracket, Upper |
| 33513A | Spring, Compression (FOR BRACKET UPPER SHAFT) |
| 33517 | Retainer, Control Shaft Upper Spring |
| 33518 | Bush, Upper Control Shaft Piece |
| 33518A | Washer, Plate (FOR UPPER CONTROL SHAFT PIECE BUSH) |
| 33518B | Ring, E (FOR UPPER CONTROL SHAFT PIECE BUSH) |
| 33522 | Seat, Shift Lever Plate (FOR COLUMN SHIFT) |
| 33523 | Pin, Shift Lever (FOR COLUMN SHIFT) |
| 33523A | Spring, Compression |
| 33523E | Ring, E (FOR SHIFT LEVER PIN) |
| 33530 | Lever Assy, Shift (FOR COLUMN SHIFT) |
| 33535 | Lever, Control Select (FOR COLUMN SHIFT) |
| 33535A | Bush (FOR CONTROL SELECT LEVER) |
| 33535E | Collar (FOR CONTROL SELECT LEVER) |
| 33536 | Shaft, Control Select Lever (FOR COLUMN SHIFT) |
| 33571 | Bracket, Control Shaft, Lower (FOR COLUMN SHIFT) |
| 33572 | Bush, Control Shaft Lower (FOR COLUMN SHIFT) |
| 33574 | Retainer, Dust Seal (FOR COLUMN SHIFT CONTROL SHAFT) |
| 33602 | Lever Sub-assy, Select (FOR COLUMN SHIFT) |
| 33607 | Support Sub-assy, Control Rod (FOR COLUMN SHIFT) |
| 33643 | Lever, Gear Selecting |
| 33643A | Bush (FOR SELECTING, NO.1 LEVER) |
| 33670A | Bush (FOR CONTROL ROD SUPPORT) |
| 33670C | Cover, Dust (FOR CONTROL ROD SUPPORT) |
| 33670E | Ring, Snap (FOR CONTROL ROD SUPPORT) |
| 33705 | Support Sub-assy, Cross Shaft (FOR BODY SIDE) |
| 33711 | Lever, Control Shaft (FOR COLUMN SHIFT) |
| 33711G | Bolt, Control Shaft Lever Lock |
| 33723 | Swivel, Connecting Rod (FOR COLUMN SHIFT) |
| 33723A | Bush (FOR COLUMN SHIFT CONTROL SHAFT) |
| 33723B | Grommet (FOR COLUMN SHIFT CONTROL SHAFT) |
| 33731 | Rod, Gear Selecting, NO.1 (FOR COLUMN SHIFT) |
| 33731A | Pin, W/Hole (FOR COLUMN SHIFT GEAR SELECTING ROD) |
| 33732 | Guide, Selecting Rod |
| 33736 | Rod, Gear Selecting, NO.2(FOR COLUMN SHIFT) |
| 33736B | Bush(FOR GEAR SELECTING ROD, NO.2) |
| 33736C | Grommet(FOR GEAR SELECTING ROD, NO.2) |
| 33736E | Swivel, Connecting Rod |
| 33740 | End Assy, Connecting Rod, NO.1(FOR COLUMN SHIFT) |
| 33741 | Rod, Gear Shifting, NO.1 (FOR COLUMN SHIFT) |
| 33742 | Rod, Gear Shifting, NO.2(FOR COLUMN SHIFT) |
| 33742A | Bush(FOR SHIFTING ROD NO.2) |
| 33742C | Spacer(FOR SHIFTING, NO.2 ROD) |
| 33743 | Rod, Gear Shifting, NO.3 (FOR COLUMN SHIFT) |
| 33743E | Spacer(FOR SHIFTING) |
| 33743F | Bush(FOR SHIFTING) |
| 33744 | Lever, Gear Shifting, NO.1 (FOR COLUMN SHIFT) |
| 33744G | Bush (FOR SHIFTING, NO.1) |
| 33744H | Collar(FOR SHIFTING, NO.1) |
| 33745 | Lever, Gear Shifting, NO.2 (FOR COLUMN SHIFT) |
| 33745A | Bush (FOR SHIFTING, NO.2 LEVER) |
| 33745B | Shaft (FOR SHIFTING, NO.2 LEVER) |
| 33749 | Lever, Gear Shifting, NO.3 (FOR COLUMN SHIFT) |
| 33749B | Bush (FOR COLUMN SHIFT GEAR SHIFTING LEVER) |
| 33751 | Support, Gear Shift Link Lever (FOR COLUMN SHIFT) |
| 33771 | Shaft, Cross (FOR COLUMN SHIFT) |
| 33772 | Bush, NO.1, Cross Shaft Support (FOR COLUMN SHIFT) |
| 33773 | Support, Cross Shaft, NO.1 (FOR COLUM SHIFT) |
| 33773A | Ring, Hole Snap (FOR CROSS SHAFT SUPPORT SNAP) |
| 33775 | Cover, Cross Shaft Dust (FOR COLUMN SHIFT) |
| 33775A | Cover, Cross Shaft Dust |
| 33776 | Bracket, Cross Shaft, NO.1 (FOR COLUMN SHIFT) |
| 33777 | Rod, Gear Shift(FOR COLUMN SHIFT) |
| 33793 | Bracket, Cross Shaft, NO.2(FOR COLUMN SHIFT) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
