Toyota Town/Masterace V,WG
1976-10 → 1982-10 · chassis KR1#,RR1#,2#,TR1# · catalogue 651110 · Japan
Discontinued model
Data version 1983-03
Heating & Air Conditioning - Control & Air Duct
36 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 55905 | Cable Sub-assy, Defrost Control |
| 55906 | Cable Sub-assy, Heater Control |
| 55906A | Cable Sub-assy, Defroster Damper Control |
| 55907A | Cable Sub-assy, Water Valve Control |
| 55908A | Cable Sub-assy, Air Inlet Damper Control |
| 55909A | Cable Sub-assy, Airmix Damper Control |
| 55910 | Control Assy, Heater OR Boost Ventilator |
| 55931 | Clamp, Heater Control Wire |
| 55937 | Knob, Heater Control Lever |
| 55939 | Ornament, Heater Control |
| 55941 | Bracket, Heater Control |
| 55956 | Nozzle, Side Defroster |
| 87125 | Louver, Ventilation |
| 87211 | Duct, Air, NO.1 |
| 87211A | Duct, Air, NO.2 |
| 87211D | Cover, Heater Air Duct Hole |
| 87214 | Duct, Air, Side NO.1 RH |
| 87214A | Duct, Air, Side NO.2 RH |
| 87215 | Duct, Air, Side NO.1 LH |
| 87231 | Hose, Heater Defroster, RH |
| 87231A | Duct, Heater Defroster, Side NO.1 RH |
| 87231B | Duct, Heater Defroster, Side NO.2 RH |
| 87231C | Duct, Heater Defroster, Side NO.3 RH |
| 87232 | Hose, Heater Defroster, LH |
| 87232A | Duct, Heater Defroster, Side NO.1 LH |
| 87232B | Duct, Heater Defroster, Side NO.2 LH |
| 88561B | Grille, Cooler Air Inlet |
| 88565A | Adapter, Air Duct, NO.1 |
| 88566A | Duct, Cooler Air, NO.1 |
| 88566B | Duct, Cooler Air, NO.2 |
| 88566C | Duct, Cooler Air, NO.3 |
| 88576C | Duct, Cooler Air, NO.1 |
| 88605A | Harness Sub-assy, Cooler Wiring |
| 88635C | Resistor, Cooler Air Duct, NO.1 |
| 88635D | Resistor, Cooler Air Duct, NO.2 |
| 88653A | Spacer, Cooler Air Duct |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
