Toyota Town/Masterace V,WG
1982-11 → 1988-08 · chassis KR26,YR2#,3#,CR2#,3# · catalogue 651120 · Japan
Discontinued model
Data version 1988-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 52111 — Bumper Assy, Front | ||||
| 52018-29045 |
Bumper Assy, Front
1982-11 → 1986-11
ended
|
CR26,27,36,KR26,YR26 | ¥34,200 | |
| 52018-87012 |
Bumper Assy, Front
1986-11 → 1988-08
ended
|
CR26,27,36,KR26,YR26 | ¥33,700 | |
| 52112D — Extension, Front Bumper, RH | ||||
| 52102-29125 |
Extension, Front Bumper, RH
1982-11 → 1988-08
ended
|
CR26,27,36,KR26,YR26 | ¥9,300 | |
| 52102-87002-01 note |
Extension, Front Bumper, RH
1985-08 → 1988-08
ended
|
YR20 6S,08S HRF E;YR20 +6 | ¥2,530 | |
| 52102-87003-03 note |
Extension, Front Bumper, RH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-04 note |
Extension, Front Bumper, RH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-05 note |
Extension, Front Bumper, RH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-06 note |
Extension, Front Bumper, RH
1985-08 → 1986-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-08 note |
Extension, Front Bumper, RH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-13 note |
Extension, Front Bumper, RH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-14 note |
Extension, Front Bumper, RH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-16 note |
Extension, Front Bumper, RH
1986-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-18 note |
Extension, Front Bumper, RH
1986-04 → 1986-08
ended
|
CR21,YR20,21 HRF E | ¥3,760 | |
| 52102-87003-28 note |
Extension, Front Bumper, RH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-44 note |
Extension, Front Bumper, RH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87003-54 note |
Extension, Front Bumper, RH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52102-87004 note |
Extension, Front Bumper, RH
1986-10 → 1986-11
ended
|
CR21,YR20,21 HRF E | — | |
| 52102-87005 note |
Extension, Front Bumper, RH
1987-04 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF E | ¥2,510 | |
| 52102-87006 note |
Extension, Front Bumper, RH
1987-09 → 1988-01
ended
|
CR21,30,YR21,30 E | ¥2,510 | |
| 52102-87007-05 note |
Extension, Front Bumper, RH
1988-01 → 1988-08
ended
|
CR21,30,YR21,30 E | ¥2,510 | |
| 52102-95D01 note |
Extension, Front Bumper, RH
1986-10 → 1986-11
ended
|
CR30,YR30 E | — | |
| 52102-95D02 note |
Extension, Front Bumper, RH
1986-10 → 1986-11
ended
|
CR21,30,YR20,21,30 HRF E | ¥2,480 | |
| 52112-28020 |
Extension, Front Bumper, RH
1983-05 → 1985-08
ended
|
YR21 G | ¥2,980 | |
| 52112-87003 note |
Extension, Front Bumper, RH
1983-09 → 1983-11
ended
|
YR20 MRF 5F G | ¥5,900 | |
| 52113D — Extension, Front Bumper, LH | ||||
| 52103-29185 |
Extension, Front Bumper, LH
1982-11 → 1988-08
ended
|
CR26,27,36,KR26,YR26 | ¥9,300 | |
| 52103-87002-01 note |
Extension, Front Bumper, LH
1985-08 → 1988-08
ended
|
YR20 6S,08S HRF E;YR20 +6 | ¥2,530 | |
| 52103-87003-03 note |
Extension, Front Bumper, LH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-04 note |
Extension, Front Bumper, LH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-05 note |
Extension, Front Bumper, LH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-06 note |
Extension, Front Bumper, LH
1985-08 → 1986-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-08 note |
Extension, Front Bumper, LH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-13 note |
Extension, Front Bumper, LH
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-14 note |
Extension, Front Bumper, LH
1985-08 → 1987-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-16 note |
Extension, Front Bumper, LH
1986-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-18 note |
Extension, Front Bumper, LH
1986-04 → 1986-08
ended
|
CR21,YR20,21 HRF E | ¥3,760 | |
| 52103-87003-28 note |
Extension, Front Bumper, LH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-44 note |
Extension, Front Bumper, LH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87003-54 note |
Extension, Front Bumper, LH
1987-08 → 1988-08
ended
|
CR21,30,YR20,21,30 E,Q | ¥3,760 | |
| 52103-87004 note |
Extension, Front Bumper, LH
1986-10 → 1986-11
ended
|
CR21,YR20,21 HRF E | ¥3,760 | |
| 52103-87005 note |
Extension, Front Bumper, LH
1987-04 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF E | ¥2,510 | |
| 52103-87006 note |
Extension, Front Bumper, LH
1987-09 → 1988-01
ended
|
CR21,30,YR21,30 E | ¥2,510 | |
| 52103-87007-05 note |
Extension, Front Bumper, LH
1988-01 → 1988-08
ended
|
CR21,30,YR21,30 E | ¥2,510 | |
| 52103-95D00 note |
Extension, Front Bumper, LH
1986-10 → 1986-11
ended
|
CR30,YR30 E | — | |
| 52103-95D01 note |
Extension, Front Bumper, LH
1986-10 → 1986-11
ended
|
CR21,30,YR20,21,30 HRF E | ¥2,480 | |
| 52113-28010 |
Extension, Front Bumper, LH
1983-05 → 1985-08
ended
|
YR21 G | ¥2,980 | |
| 52113-87002 note |
Extension, Front Bumper, LH
1983-10 → 1983-11
ended
|
YR20 MRF 5F G | ¥5,900 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
