Toyota Town/Masterace V,WG
1982-11 → 1988-08 · chassis KR26,YR2#,3#,CR2#,3# · catalogue 651120 · Japan
Discontinued model
Data version 1988-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 04319 — Cup Kit, Clutch Accumulator | ||||
| 04319-27010 |
Cup Kit, Clutch Accumulator
1985-08 → 1988-08
ended
|
CR21,26,28,3# 5F | ¥2,520 | |
| 04319-28010 |
Cup Kit, Clutch Accumulator
1984-07 → 1985-08
ended
|
CR21,26 5F | ¥2,370 | |
| 31478A — Cap, Bleeder Plug(FOR CLUTCH ACCUMULATOR) | ||||
| 31478-30010 |
Cap, Bleeder Plug(FOR CLUTCH ACCUMULATOR)
1984-07 → 1988-08
ended
|
CR21,26,28,30,36 5F | ¥160 | |
| 31490 — Accumulator Assy, Clutch | ||||
| 31490-28010 |
Accumulator Assy, Clutch
1984-07 → 1985-08
ended
|
CR21,26 5F | ¥5,800 | |
| 31490-28020 |
Accumulator Assy, Clutch
1985-08 → 1988-08
ended
|
CR21,26,28,3# 5F | ¥6,300 | |
| 31490A — Plug, Bleeder(FOR CLUTCH ACCUMULATOR) | ||||
| 47547-12010 |
Plug, Bleeder(FOR CLUTCH ACCUMULATOR)
1984-07 → 1988-08
ended
|
CR21,26,28,30,36 5F | ¥180 | |
| 31493 — Bracket, Clutch Accumulator | ||||
| 31493-28010 |
Bracket, Clutch Accumulator
1984-07 → 1985-08
ended
|
CR21,26 5F | — | |
| 31493-28020 |
Bracket, Clutch Accumulator
1985-08 → 1988-08
ended
|
CR21,26,28,30,36 5F | ¥1,780 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
