Toyota Town/Masterace V,WG
1982-11 → 1988-08 · chassis KR26,YR2#,3#,CR2#,3# · catalogue 651120 · Japan
Discontinued model
Data version 1988-11
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 87226 — Adapter, Air Duct | ||||
| 87226-28010 note |
Adapter, Air Duct
1983-08 → 1984-08
ended
|
CR21,YR20,21 MRF (E,X) | — | |
| 87226-28010 note |
Adapter, Air Duct
1984-08 → 1988-08
ended
|
YR20 MRF E;YR20 MRF +4 | — | |
| 87226-87003 note |
Adapter, Air Duct
1982-11 → 1984-08
ended
|
YR20 HRF 5F G;CR21,YR20,21 +1 | — | |
| 87226-87003 note |
Adapter, Air Duct
1985-08 → 1988-08
ended
|
YR20 HRF (E,Q);YR20 HRF +3 | — | |
| 87226-87003 note |
Adapter, Air Duct
1984-08 → 1985-08
ended
|
YR20 MRF 5F G;CR21,YR20,21 +1 | — | |
| 87226-87004 note |
Adapter, Air Duct
1982-11 → 1983-08
ended
|
CR21,YR21 MRF;YR20 MRF (E,X);YR20 +3 | — | |
| 87226-87005 note |
Adapter, Air Duct
1982-11 → 1985-08
ended
|
CR21,YR20,21 HRF | — | |
| 87226-87005 note |
Adapter, Air Duct
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 88565-87001-03 note |
Adapter, Air Duct
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 88565-87001-03 note |
Adapter, Air Duct
1982-11 → 1985-08
ended
|
CR21,YR20 E | — | |
| 88565-87001-05 note |
Adapter, Air Duct
1982-11 → 1984-08
ended
|
CR21,YR20 08S | — | |
| 88565-87001-15 note |
Adapter, Air Duct
1984-08 → 1985-08
ended
|
CR21,YR20 E,G | — | |
| 88565-87001-25 note |
Adapter, Air Duct
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 87284 — Resistor Sub-assy, Variable | ||||
| 88032-87001 note |
Resistor Sub-assy, Variable
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 Q | — | |
| 88032-87002 note |
Resistor Sub-assy, Variable
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 Q | — | |
| 88622-87001 |
Resistor Sub-assy, Variable
1982-11 → 1985-08
ended
|
CR21,YR20,21 E,G,Q,X | — | |
| 88622-87001 note |
Resistor Sub-assy, Variable
1983-10 → 1983-11
ended
|
YR20 MRF 5F G | — | |
| 88566A — Duct, Cooler Air, NO.1 | ||||
| 88566-87013-03 note |
Duct, Cooler Air, NO.1
1982-11 → 1984-08
ended
|
CR21,YR20 MRF E | — | |
| 88566-87013-05 note |
Duct, Cooler Air, NO.1
1982-11 → 1984-08
ended
|
CR21,YR20 MRF 08S | — | |
| 88566-87014-03 note |
Duct, Cooler Air, NO.1
1982-11 → 1985-08
ended
|
CR21,YR20 HRF E | — | |
| 88566-87014-05 note |
Duct, Cooler Air, NO.1
1982-11 → 1985-08
ended
|
CR21,YR20 HRF 08S | — | |
| 88566-87016-03 note |
Duct, Cooler Air, NO.1
1984-08 → 1985-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88566-87017-03 note |
Duct, Cooler Air, NO.1
1985-08 → 1988-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88566-87017-05 note |
Duct, Cooler Air, NO.1
1985-08 → 1988-08
ended
|
YR20 HRF 5F G;CR21,YR20 +2 | — | |
| 88566-87018-03 note |
Duct, Cooler Air, NO.1
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 HRF +4 | — | |
| 88566-87018-05 note |
Duct, Cooler Air, NO.1
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 HRF +4 | — | |
| 88570E — Grille Assy, Air Outlet | ||||
| 87125-87003-03 note |
Grille Assy, Air Outlet
1982-11 → 1984-08
ended
|
CR21,YR20,21 E,Q,X | — | |
| 87125-87003-03 note |
Grille Assy, Air Outlet
1984-08 → 1985-08
ended
|
YR20 HRF;YR20 MRF (E,X);YR20 +4 | — | |
| 87125-87003-03 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 87125-87003-05 note |
Grille Assy, Air Outlet
1982-11 → 1984-08
ended
|
CR21,YR20,21 E,Q,X | — | |
| 87125-87003-15 note |
Grille Assy, Air Outlet
1984-08 → 1985-08
ended
|
YR20 HRF;YR20 MRF (E,X);YR20 +4 | — | |
| 87125-87003-25 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 88570-28010-03 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 88570-28010-03 note |
Grille Assy, Air Outlet
1984-08 → 1985-08
ended
|
CR21,YR20 E,G | — | |
| 88570-28010-15 note |
Grille Assy, Air Outlet
1984-08 → 1985-08
ended
|
CR21,YR20 E,G | — | |
| 88570-28010-25 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 88570-87001-03 note |
Grille Assy, Air Outlet
1982-11 → 1984-08
ended
|
CR21,YR20 E | — | |
| 88570-87001-05 note |
Grille Assy, Air Outlet
1982-11 → 1984-08
ended
|
CR21,YR20 08S | — | |
| 88570-87002-03 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 88570-87002-05 note |
Grille Assy, Air Outlet
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 88648A — Wiring, Cooler | ||||
| 88648-87009 |
Wiring, Cooler
1983-10 → 1985-08
ended
|
CR21,YR20 E,G | — | |
| 88688H — Bracket, Cooler Air Duct, NO.1 | ||||
| 88688-87014 |
Bracket, Cooler Air Duct, NO.1
1984-08 → 1988-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88688-87015 |
Bracket, Cooler Air Duct, NO.1
1982-11 → 1984-08
ended
|
CR21,YR20 08S | — | |
| 88688-87015 |
Bracket, Cooler Air Duct, NO.1
1984-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF 08S | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
