Toyota Town/Masterace V,WG
1982-11 → 1988-08 · chassis KR26,YR2#,3#,CR2#,3# · catalogue 651120 · Japan
Discontinued model
Data version 1988-11
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 88800B — Cool Box And Accessory Assy, NO.1 | ||||
| 88800-87001-03 note |
Cool Box And Accessory Assy, NO.1
1982-11 → 1984-06
ended
|
YR20,21 E,Q,X | — | |
| 88800-87001-05 note |
Cool Box And Accessory Assy, NO.1
1982-11 → 1984-06
ended
|
YR20,21 07S,08S | — | |
| 88800-87006-03 note |
Cool Box And Accessory Assy, NO.1
1983-04 → 1985-08
ended
|
CR21 E,G | — | |
| 88800-87006-05 note |
Cool Box And Accessory Assy, NO.1
1983-04 → 1985-08
ended
|
CR21 E,G | — | |
| 88800-87007-02 note |
Cool Box And Accessory Assy, NO.1
1984-08 → 1985-08
ended
|
YR20,21 07S,08S | — | |
| 88800-87007-03 note |
Cool Box And Accessory Assy, NO.1
1984-06 → 1984-08
ended
|
YR20,21 E,Q,X | — | |
| 88800-87007-04 note |
Cool Box And Accessory Assy, NO.1
1984-08 → 1985-08
ended
|
YR20,21 E,Q,X | — | |
| 88800-87007-05 note |
Cool Box And Accessory Assy, NO.1
1984-06 → 1984-08
ended
|
YR20,21 07S,08S | — | |
| 88800-87008-04 note |
Cool Box And Accessory Assy, NO.1
1985-08 → 1986-08
ended
|
YR20 MRF 08S;YR20 HRF +4 | — | |
| 88800-87008-04 note |
Cool Box And Accessory Assy, NO.1
1985-10 → 1986-08
ended
|
CR30,YR30 | — | |
| 88800-87008-06 note |
Cool Box And Accessory Assy, NO.1
1985-08 → 1986-08
ended
|
YR20 MRF 08S;YR20 HRF +4 | — | |
| 88800-87008-06 note |
Cool Box And Accessory Assy, NO.1
1985-10 → 1986-08
ended
|
CR30,YR30 | — | |
| 88800-87009-04 note |
Cool Box And Accessory Assy, NO.1
1985-08 → 1986-08
ended
|
CR21 E,G,Q | — | |
| 88800-87009-06 note |
Cool Box And Accessory Assy, NO.1
1985-08 → 1986-08
ended
|
CR21 E,G,Q | — | |
| 88800-87014-04 note |
Cool Box And Accessory Assy, NO.1
1986-08 → 1986-09
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 88800-87014-04 note |
Cool Box And Accessory Assy, NO.1
1986-08 → 1987-08
ended
|
CR30,YR30 | — | |
| 88800-87014-04 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
CR30 5F | — | |
| 88800-87014-04 note |
Cool Box And Accessory Assy, NO.1
1986-09 → 1988-08
ended
|
CR21,YR21 E,G,Q | — | |
| 88800-87014-06 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
CR30 5F | — | |
| 88800-87014-06 note |
Cool Box And Accessory Assy, NO.1
1986-09 → 1988-08
ended
|
CR21,YR21 E,G,Q | — | |
| 88800-87014-06 note |
Cool Box And Accessory Assy, NO.1
1986-08 → 1987-08
ended
|
CR30,YR30 | — | |
| 88800-87014-06 note |
Cool Box And Accessory Assy, NO.1
1986-08 → 1986-09
ended
|
YR20 HRF E;YR20 MRF +5 | — | |
| 88800-87018-04 note |
Cool Box And Accessory Assy, NO.1
1986-09 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +4 | — | |
| 88800-87018-06 note |
Cool Box And Accessory Assy, NO.1
1986-09 → 1988-08
ended
|
YR20 HRF E;YR20 MRF +4 | — | |
| 88800-95D07-04 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
CR30 4FC | — | |
| 88800-95D07-04 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
YR30 | — | |
| 88800-95D07-06 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
CR30 4FC | — | |
| 88800-95D07-06 note |
Cool Box And Accessory Assy, NO.1
1987-08 → 1988-08
ended
|
YR30 | — | |
| 88820 — Air Conditioner & Accessory Sub-assy, NO.1 | ||||
| 88820-87001 note |
Air Conditioner & Accessory Sub-assy, NO.1
1985-08 → 1988-08
ended
|
YR20 MRF 08S;CR21,YR21 E,G,Q;YR20 +5 | — | |
| 88820-87002 |
Air Conditioner & Accessory Sub-assy, NO.1
1985-08 → 1988-08
ended
|
CR26,27,KR26,YR26 | — | |
| 88820-87002 |
Air Conditioner & Accessory Sub-assy, NO.1
1985-08 → 1988-08
ended
|
CR21,28,YR20,28 B,D | — | |
| 88820-95D01 note |
Air Conditioner & Accessory Sub-assy, NO.1
1985-10 → 1988-08
ended
|
YR30 | — | |
| 88820-95D02 note |
Air Conditioner & Accessory Sub-assy, NO.1
1985-10 → 1988-08
ended
|
CR30 | — | |
| 88820-95D03 |
Air Conditioner & Accessory Sub-assy, NO.1
1985-10 → 1988-08
ended
|
CR36,37 | — | |
| 88820A — Air Conditioner & Accessory Sub-assy, NO.2 | ||||
| 88830-87001 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
YR20 MRF 08S;YR20 HRF +4 | — | |
| 88830-87002 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
YR21 | — | |
| 88830-87003 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
CR21 E,G,Q | — | |
| 88830-87004 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
CR2# B,D,N | — | |
| 88830-87005 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
YR20,26,28 B,D,N | — | |
| 88830-87006 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-08 → 1988-08
ended
|
KR26 | — | |
| 88830-95D01 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-10 → 1988-08
ended
|
YR30 | — | |
| 88830-95D02 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-10 → 1988-08
ended
|
CR30 | — | |
| 88830-95D03 note |
Air Conditioner & Accessory Sub-assy, NO.2
1985-10 → 1988-08
ended
|
CR36,37 | — | |
| 88830-95D04 note |
Air Conditioner & Accessory Sub-assy, NO.2
1986-08 → 1988-08
ended
|
YR36 | — | |
| 88830-95D05 note |
Air Conditioner & Accessory Sub-assy, NO.2
1987-08 → 1988-08
ended
|
CR30 4FC | — | |
| 88820B — Air Conditioner & Accessory Sub-assy, NO.3 | ||||
| 88840-95D01 note |
Air Conditioner & Accessory Sub-assy, NO.3
1985-10 → 1988-08
ended
|
CR30 | — | |
| 88840-95D02 note |
Air Conditioner & Accessory Sub-assy, NO.3
1987-08 → 1988-08
ended
|
CR30 | — | |
| 88860 — Accessory Assy, Automatic Air Conditioner | ||||
| 88860-87001 |
Accessory Assy, Automatic Air Conditioner
1985-08 → 1986-08
ended
|
YR20 Q | — | |
| 88860-87002 |
Accessory Assy, Automatic Air Conditioner
1985-08 → 1986-08
ended
|
YR21 Q | — | |
| 88860-87003 |
Accessory Assy, Automatic Air Conditioner
1985-08 → 1986-08
ended
|
CR21 Q | — | |
| 88860-87004 |
Accessory Assy, Automatic Air Conditioner
1986-08 → 1988-08
ended
|
YR21 Q | — | |
| 88860-87005 |
Accessory Assy, Automatic Air Conditioner
1986-08 → 1988-08
ended
|
CR21 Q | — | |
| 88860-95D01 |
Accessory Assy, Automatic Air Conditioner
1985-10 → 1986-08
ended
|
CR30 Q | ¥42,000 | |
| 88860-95D02 |
Accessory Assy, Automatic Air Conditioner
1986-08 → 1988-08
ended
|
YR30 Q | — | |
| 88860-95D03 |
Accessory Assy, Automatic Air Conditioner
1986-08 → 1988-08
ended
|
CR30 Q | — | |
| 88870 — Duct And Accessory Assy | ||||
| 88870-87001-03 note |
Duct And Accessory Assy
1982-11 → 1984-08
ended
|
CR21,YR20 MRF E | — | |
| 88870-87001-05 note |
Duct And Accessory Assy
1982-11 → 1984-08
ended
|
CR21,YR20 MRF 08S | — | |
| 88870-87002-03 note |
Duct And Accessory Assy
1982-11 → 1984-08
ended
|
CR21,YR20 HRF E | — | |
| 88870-87002-05 note |
Duct And Accessory Assy
1982-11 → 1984-08
ended
|
CR21,YR20 HRF 08S | — | |
| 88870-87003 note |
Duct And Accessory Assy
1983-10 → 1983-11
ended
|
YR20 MRF 5F G | — | |
| 88870-87003 note |
Duct And Accessory Assy
1982-11 → 1984-08
ended
|
CR21,YR21;YR20 HRF;YR20 MRF (E,X) | — | |
| 88870-87004-03 note |
Duct And Accessory Assy
1984-08 → 1985-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88870-87004-05 note |
Duct And Accessory Assy
1984-08 → 1985-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88870-87005-03 note |
Duct And Accessory Assy
1984-08 → 1985-08
ended
|
CR21,YR20 HRF 08S | — | |
| 88870-87005-05 note |
Duct And Accessory Assy
1984-08 → 1985-08
ended
|
CR21,YR20 HRF 08S | — | |
| 88870-87006 note |
Duct And Accessory Assy
1984-08 → 1985-08
ended
|
YR21;CR21,YR20 E,Q,X | — | |
| 88870-87011-03 note |
Duct And Accessory Assy
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 HRF +4 | — | |
| 88870-87011-05 note |
Duct And Accessory Assy
1985-08 → 1988-08
ended
|
YR20 HRF E;YR20 HRF +4 | — | |
| 88870-87012 note |
Duct And Accessory Assy
1985-08 → 1988-08
ended
|
CR21,30,YR20,21,30 HRF (E,Q) | — | |
| 88870-87013-03 note |
Duct And Accessory Assy
1985-08 → 1988-08
ended
|
CR21,YR20 MRF (E,G) | — | |
| 88870-87013-05 note |
Duct And Accessory Assy
1985-08 → 1988-08
ended
|
CR21,YR20 MRF (E,G) | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
