Toyota Town/Masterace V,WG

1988-08 → 1992-01 · chassis KR2#,YR2#,3#,CR2#,3# · catalogue 651130 · Japan

Discontinued model Data version 1992-09
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Front Bumper & Bumper Stay

6 part groups · 2 illustrations

Illustrations

Figure MBP988B MBP988B 1988-08 → — Figure MBP989B MBP989B 1988-08 → —

Part groups

PNCDescription
52021A Reinforcement Sub-assy, Front Bumper, RH
52022A Reinforcement Sub-assy, Front Bumper, LH
52116B Retainer, Front Bumper
52119A Cover, Front Bumper
52134D Reinforcement, Front Bumper Stay
52543A Seal, Front Bumper Side
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
