Toyota Town/Masterace V,WG

1988-08 → 1992-01 · chassis KR2#,YR2#,3#,CR2#,3# · catalogue 651130 · Japan

Discontinued model Data version 1992-09

Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Front Floor Panel & Front Floor Member

87 part groups · 3 illustrations

Illustrations

MBP998F 1988-08 → —

MBP999B 1988-08 → —

MBR073A 1988-08 → —

Part groups

PNC	Description
51025	Member Sub-assy, Engine Front Mounting
51296A	Bolt, Engine Front Support Member
51431B	Bracket, Engine Rear Mounting
51432	Bracket, Engine Rear Mounting, LH
51469A	Trim, Engine Cover, NO.1
51479	Trim, Engine Cover, NO.2
53204C	Support Sub-assy, Radiator Reserver Tank
53253A	Bracket, Radiator Mounting, Upper
53261	Bracket, Radiator Reserve Tank Mounting
53287A	Cover, Cooler Pipe Hole
53701	Apron Sub-assy, Front Fender, RH
53702	Apron Sub-assy, Front Fender, LH
53707B	Apron Sub-assy, Fender Side, RH
53708B	Apron Sub-assy, Fender Side, LH
53757A	Bracket, Heater Hose Mounting
53885C	Seal, Fender Apron Mudguard, RH
53886C	Seal, Fender Apron Mudguard, LH
55143	Bracket, Cowl Side Trim Mounting, NO.1
55763	Bracket, Cooler Mounting
57045	Plate Sub-assy, Floor Side Rail, RH
57046	Plate Sub-assy, Floor Side Rail, LH
57101	Member Sub-assy, Front Side, RH
57102	Member Sub-assy, Front Side, LH
57104A	Member Sub-assy, Front Cross
57115A	Plate, Front Side Member, Outer RH
57116A	Plate, Front Side Member, Outer LH
57119A	Plate, Front Side Member, Front RH
57129A	Plate, Front Side Member, Front LH
57209A	Member Sub-assy, Engine Rear Mounting
57218	Gusset, Front Side Member, NO.1
57218A	Gusset, Front Side Member, NO.1 LH
57219	Gusset, Front Side Member, NO.2
57229A	Gusset, Front Side Member, NO.2 LH
57311	Outrigger, NO.1 RH
57312	Outrigger, NO.1 LH
57417	Reinforcement, Front Floor Under, RH
57418	Reinforcement, Front Floor Under, LH
57423	Bracket, Front Floor Reinforcement, RH
57424	Bracket, Front Floor Reinforcement, LH
57505	Bracket Sub-assy, Parking Brake, NO.1
58083	Hinge Sub-assy, Battery Service Cover, Male
58111	Pan, Front Floor
58181A	Retainer, Seat Rail, Front
58183A	Retainer, Seat Rail, Rear RH
58186A	Bracket, Brake Tube Set
58187A	Bracket, Vacuum Tube Clamp
58191	Footrest, Front Floor
58205B	Hinge Sub-assy, Battery Service Cover Male
58236C	Bracket, Clutch Tube
58319D	Retainer, Jack Cover
58407A	Cover Sub-assy, Engine Service Hole Sub
58410	Cover, Engine Service Hole
58410D	Cushion, NO.1
58410E	Cushion, NO.3
58416A	Plate, Engine Sub Cover
58435A	Packing, Engine Main Cover
58435B	Hook, Engine Service Hole Cover, LH
58436A	Packing, Engine Sub Cover, NO.1
58436B	Hook, Engine Service Hole Cover, Center
58439C	Hook, Engine Main Cover Catch, Center
58440	Cover Assy, Battery Service Hole
58445	Packing, Battery Service Hole Cover
58457G	Hook, Engine Main Cover Catch, LH
58467F	Packing, Inspection Hole
58470	Cover Assy, Inspection Hole
58471C	Silencer, Engine Main Cover
58472A	Silencer, Engine Sub Cover
58476	Retainer, Engine Service Hole Cover Catch
58478A	Packing, Engine Sub Cover, NO.2
58479A	Packing, Engine Sub Cover, NO.3
58491	Retainer, Engine Cover, NO.1
58492	Retainer, Engine Cover, NO.2
58495	Trim, Inspection Hole Cover
58936A	Band, Engine Service Hole Cover Support
58938A	Cushion, Engine Service Hole Cover Band
59409	Retainer Sub-assy, Footrest NO.2, LH
59450	Rest Assy, Front Floor Foot, NO.2
59462	Retainer, Front Floor Footrest NO.2 Stay
59471	Knob, Front Floor Footrest NO.2 Control
61793A	Bracket, Cooler Condenser, NO.1
61794A	Bracket, Cooler Condenser, NO.2
71035	Cushion Sub-assy, Seat Stopper
71370C	Catch Assy, FR Seat Cushion
76073	Protector Sub-assy, Steering Main Shaft, RH
76074	Protector Sub-assy, Steering Main Shaft, LH
76610F	Protector Assy, Steering Main Shaft, RH
78118A	Stopper, Accelerator Pedal

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
