Toyota Town/Masterace V,WG
1988-08 → 1992-01 · chassis KR2#,YR2#,3#,CR2#,3# · catalogue 651130 · Japan
Discontinued model
Data version 1992-09
Inside Trim Board
32 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58076 | Cover Sub-assy, Jack Box Hole |
| 62103C | Clip, Cowl Side Trim Board Set |
| 62111C | Board, Cowl Side Trim, RH |
| 62112 | Board, Cowl Side Trim, LH |
| 62211 | Garnish, Front Pillar, RH |
| 62212 | Garnish, Front Pillar, LH |
| 62313D | Trim, Front Door Opening, RH |
| 62314D | Trim, Front Door Opening, LH |
| 62411 | Garnish, Center Pillar, RH |
| 62411B | Garnish, Center Pillar, Upper RH |
| 62412 | Garnish, Center Pillar, LH |
| 62412B | Garnish, Center Pillar, Upper LH |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62425B | Cover, Center Pillar Garnish, NO.3 RH |
| 62426B | Cover, Center Pillar Garnish, NO.3 LH |
| 62441A | Garnish, Roof Side Rail, NO.2 RH |
| 62442A | Garnish, Roof Side Rail, NO.2 LH |
| 62471D | Garnish, Rear Pillar, Upper RH |
| 62472D | Garnish, Rear Pillar, Upper LH |
| 62473A | Board, Rear Pillar, RH |
| 62474A | Board, Rear Pillar, LH |
| 62510H | Clip(FOR QUARTER TRIM FRONT PANEL) |
| 62510K | Clip(FOR QUARTER TRIM FRONT PANEL) |
| 62510P | Panel Assy, Quarter Trim, Front RH |
| 62548 | Reinforcement, Quarter Trim, NO.1 |
| 62549 | Reinforcement, Quarter Trim, NO.2 |
| 62594A | Pocket, Quarter Trim, NO.1 |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62630Q | Clip (FOR QUARTER TRIM) |
| 62638A | Garnish, Quarter Pillar, RH |
| 62639A | Garnish, Quarter Pillar, LH |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
