Toyota Lite/Townace V,WG
1992-01 → 1996-10 · chassis KR27,YR2#,30,CR2#,3# · catalogue 651140 · Japan
Discontinued model
Data version 1997-05
Vacuum Piping
37 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 17303B | Pipe Sub-assy, Air, NO.1 |
| 17303G | Hose, NO.3(FOR AIR PIPE) |
| 17308 | Hose Sub-assy, Vacuum(FOR IDLE-UP) |
| 17308B | Hose Sub-assy, Vacuum |
| 17341B | Hose, NO.1(FOR AIR INJECTION SYSTEM) |
| 17341D | Hose, NO.1(FOR IDLE-UP) |
| 17341E | Clip, NO.1(FOR IDLE-UP HOSE) |
| 17342B | Hose, NO.2(FOR IDLE-UP) |
| 17342C | Clip, NO.2(FOR IDLE-UP HOSE) |
| 17343B | Hose, NO.3(FOR IDLE-UP) |
| 17343C | Clip, NO.3(FOR IDLE-UP HOSE) |
| 17630 | Valve Assy, Air Control |
| 17650 | Valve Assy, Vacuum Switching |
| 17650D | Bracket, Vacuum Switching Valve |
| 17650E | Valve, Vacuum Switching |
| 17810A | Filter Assy, Air |
| 21908C | Diaphragm Sub-assy, Idle-up |
| 23262 | Valve, Bimetal Vacuum Switching, NO.1 |
| 23265 | Filter, Gas, NO.1 |
| 23281 | Valve, Vacuum Transmitting, NO.1 |
| 23283 | Valve, Vacuum Transmitting, NO.3 |
| 23285A | Valve, Check, NO.1 |
| 23288 | Jet, NO.1 |
| 23289 | Jet, NO.2 |
| 23289B | Jet, NO.3 |
| 25693A | Damper, Egr Vacuum Modulator |
| 25706 | Pipe Sub-assy, Vacuum Transmitting, NO.1 |
| 25730 | Valve Assy, Electric Bleed Air Control |
| 25760 | Hose Assy, Vacuum Transmitting |
| 25770 | Hose Assy, Vacuum Transmitting, NO.2 |
| 25780 | Hose Assy, Vacuum Transmitting, NO.3 |
| 25810 | Valve Assy, Bimetal |
| 25819 | Valve Assy, Vacuum Regulating |
| 25850 | Valve Assy, Electric Vacuum Regulating |
| 25860 | Valve Assy, Vacuum Switching, NO.1 |
| 25860A | Valve, Vacuum Switching, NO.1 |
| 25861 | Bracket, Vacuum Switching Valve |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
