Toyota Lite/Townace V,WG
1992-01 → 1996-10 · chassis KR27,YR2#,30,CR2#,3# · catalogue 651140 · Japan
Discontinued model
Data version 1997-05
Seat & Seat Track
192 part groups · 15 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 62551D | Garnish, Rear Seat Side, RH |
| 62551E | Clip(FOR REAR SEAT SIDE GARNISH) |
| 62552D | Garnish, Rear Seat Side, LH |
| 71011S | Frame Sub-assy, Front Seat Cushion, RH |
| 71012S | Frame Sub-assy, Front Seat Cushion, LH |
| 71033 | Leg Sub-assy, Rear Seat Cushion |
| 71035S | Cover, Front Seatback, Center |
| 71037 | Hinge Sub-assy, Center Seatback, RH |
| 71038 | Hinge Sub-assy, Center Seatback, LH |
| 71071S | Cover, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71072S | Cover, Front Seat Cushion, LH(FOR SEPARATE TYPE) |
| 71073S | Cover, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71074S | Cover, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71257 | Plate, Rear Seatback Anchor |
| 71258A | Plate, Rear Seatback Anchor, LH |
| 71282 | Support, Front Seatback, LH Outer |
| 71283B | Support, Front Seatback, LH Inner |
| 71297 | Pin, Passenger Seatback Support |
| 71303C | Hinge Sub-assy, Rear Seatback, RH |
| 71304C | Hinge Sub-assy, Rear Seatback, LH |
| 71305S | Frame Sub-assy, Center Seatback |
| 71306D | Bracket Sub-assy, Front Seat Set |
| 71324A | Cushion, Rear Seat |
| 71324B | Cushion, Rear Seat |
| 71338A | Plate, Rear Seat Leg, NO.2 |
| 71339 | Plate, RR Seat Leg, NO.3 |
| 71349B | Cover, Rear Seatback Stay, RH |
| 71350S | Back Assy, Front Seat, Center |
| 71362 | Bracket, Front Seat Set, NO.2 |
| 71369B | Cover, Rear Seatback Stay, LH |
| 71395B | Cover, Center Seat Hinge, RH |
| 71409 | Stopper Sub-assy, Rear Seatback |
| 71410S | Cushion Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71420S | Cushion Assy, Front Seat, LH (FOR SEPARATE TYPE) |
| 71430S | Back Assy, Front Seat, RH(FOR SEPARATE TYPE) |
| 71440S | Back Assy, Front Seat, LH(FOR SEPARATE TYPE) |
| 71511S | Pad, Front Seat Cushion, RH(FOR SEPARATE TYPE) |
| 71512S | Pad, Front Seat Cushion, LH (FOR SEPARATE TYPE) |
| 71537A | Protector, Front Seat Cushion |
| 71551S | Pad, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71552S | Pad, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71554A | Pad, Front Seatback, Center |
| 71587 | Protector, Front Seatback Edge |
| 71587B | Protector, Front Seatback Edge |
| 71588 | Protector, Front Seatback Edge, NO.2 |
| 71611B | Pad, Rear NO.1 Seat Cushion |
| 71629 | Cover, Rear Seat Cushion Hinge |
| 71630S | Spring Assy, Front Seatback, RH(FOR SEPARATE TYPE) |
| 71640S | Spring Assy, Front Seatback, LH(FOR SEPARATE TYPE) |
| 71651 | Pad, Rear NO.1 Seatback |
| 71667A | Pad, Rear Seatback, Center A |
| 71668A | Pad, RR Seatback, Center B |
| 71691A | Cover, Rear NO.3 Seat Lock, RH |
| 71692A | Cover, Rear NO.3 Seat Lock, LH |
| 71727B | Trim, Rear Seat Cushion |
| 71811C | Cover, Reclining Adjuster, RH |
| 71811F | Cover, Reclining Adjuster, RH |
| 71812C | Cover, Reclining Adjuster, LH |
| 71812E | Cover, Reclining Adjuster, LH |
| 71831D | Cover, Front Seat Hinge, RH |
| 71832D | Cover, Front Seat Hinge, LH |
| 71899 | Protector, Rear Seatback |
| 71910A | Headrest Assy, Front Seat |
| 71931 | Support, Front Seat Headrest |
| 71931A | Support, Rear Seat Headrest |
| 71940A | Headrest Assy, Rear Seat |
| 72011C | Adjuster Sub-assy, Front Seat, RH |
| 72012C | Adjuster Sub-assy, Front Seat, LH |
| 72065 | Belt Sub-assy, Rear Seat Hook, RH |
| 72066 | Belt Sub-assy, Rear Seat Hook, LH |
| 72093 | Plate Sub-assy, Rear Seat Turn, Lower RH |
| 72094A | Plate Sub-assy, Rear Seat Turn, Lower LH |
| 72110A | Track Assy, Front Seat, Outer RH |
| 72120 | Track Assy, Front Seat, Outer LH |
| 72130A | Track Assy, Front Seat, Inner RH |
| 72137B | Cover, Seat Track, RH |
| 72138B | Cover, Seat Track, LH |
| 72140A | Track Assy, Front Seat,Inner LH |
| 72213 | Knob, Seat Track Adjusting Handle |
| 72329 | Cover, Seat Adjuster Bolt |
| 72345 | Cap, Seat Stand Frame |
| 72381 | Rod, Reclining Adjuster Equalizing, NO.1 |
| 72525A | Handle, Reclining Adjuster Release, RH |
| 72525C | Handle, Reclining Adjuster Release, NO.1 RH |
| 72525D | Handle, Reclining Adjuster Release, NO.2 RH |
| 72526 | Handle, Reclining Adjuster Release, LH |
| 72526B | Handle, Reclining Adjuster Release, NO.1 LH |
| 72526C | Handle, Reclining Adjuster Release, NO.2 LH |
| 72551B | Cover, Reclining Hinge, RH |
| 72552B | Cover, Reclining Hinge, LH |
| 72650B | Lock Assy, Rear NO.3 Seat, RH |
| 72658B | Knob, Rear Seat Lock Handle |
| 72658D | Knob, Rear Seat Lock Handle |
| 72660B | Lock Assy, Rear NO.3 Seat, LH |
| 72670B | Lock Assy, Rear Seat Cushion, RH |
| 72680B | Lock Assy, Rear Seat Cushion, LH |
| 72687A | Holder, Rear Seatback Lock |
| 72691 | Striker, Rear NO.3 Seat Lock |
| 72693A | Striker, Rear Seat Cushion Lock, NO.3 |
| 72727D | Belt, Rear Seat Reclining Release |
| 72730A | Adjuster Assy, Rear Seat Reclining, RH |
| 72730C | Adjuster Assy, NO.2 Seat Reclining, RH |
| 72740A | Adjuster Assy, Rear Seat Reclining, LH |
| 72740C | Adjuster Assy, NO.2 Seat Reclining, LH |
| 72810A | Armrest Assy, Seat, RH |
| 72820A | Armrest Assy, Seat, LH |
| 72880 | Armrest Assy, Seat, C RH |
| 72890 | Armrest Assy, Seat, C LH |
| 72927 | Cover, Rear Seat Cushion Under, RH |
| 72928 | Cover, Rear Seat Cushion Under, LH |
| 72959 | Spacer, Rear Seat Turn Side |
| 72960B | Table Assy, Rear Seat Turn, RH |
| 72969B | Knob, Rear Seat Turn Lock, RH |
| 72969C | Knob, Rear Seat Turn Lock, LH |
| 72970 | Table Assy, Rear Seat Turn, LH |
| 72991 | Cover, Front Seat Cushion, RH |
| 72992 | Cover, Front Seat Cushion, LH |
| 72995A | Cover, Rear Seat |
| 78072 | Cover Sub-assy, Sub Seat Cushion, LH |
| 78074 | Cover Sub-assy, Sub Seatback, LH |
| 78702 | Frame Sub-assy, Sub Seat Cushion, LH |
| 78703 | Frame Sub-assy, Sub Seatback |
| 78705 | Bracket Sub-assy, Sub Seat Cushion |
| 78709 | Panel Sub-assy, Sub Seat Cushion |
| 78726 | Cushion, Sub Seat Cushion Frame |
| 78727 | Board, Sub Seat Cushion |
| 78730 | Cushion Assy, Sub Seat, LH |
| 78735 | Pad, Sub Seat Cushion |
| 78750A | Back Assy, Sub Seat, LH |
| 78775 | Pad, Sub Seatback |
| 78804 | Leg Sub Assy, Sub Seat Cushion |
| 79011 | Cover Sub-assy, NO.1 Seat Cushion, RH |
| 79011A | Cover Sub-assy, NO.1 Seat Cushion |
| 79012 | Cover Sub-assy, NO.1 Seat Cushion, LH |
| 79013 | Cover Sub-assy, NO.1 Seatback, RH |
| 79013A | Cover Sub-assy, NO.1 Seatback |
| 79014 | Cover Sub-assy, NO.1 Seatback, LH |
| 79031 | Cover Sub-assy, NO.3 Seat Cushion, RH |
| 79032 | Cover Sub-assy, NO.3 Seat Cushion, LH |
| 79033 | Cover Sub-assy, NO.3 Seatback, RH |
| 79034 | Cover Sub-assy, NO.3 Seatback, LH |
| 79035 | Leg Sub Assy, NO.3 Seat Outer Rear, RH |
| 79036 | Leg Sub Assy, NO.3 Seat Outer Rear, LH |
| 79095 | Leg Sub Assy, NO.3 Seat Outer Front, RH |
| 79096 | Leg Sub-assy, NO.3 Seat, Inner LH |
| 79105 | Leg Sub-assy, NO.1 Seat, RH |
| 79120 | Cushion Assy, NO.1 Seat, RH |
| 79120A | Cushion Assy, NO.1 Seat |
| 79130 | Cushion Assy, NO.1 Seat, LH |
| 79135A | Pad, NO.1 Seat Cushion, RH |
| 79136A | Cover, NO.1 Seat Leg, A |
| 79136B | Pad, NO.1 Seat Cushion, LH |
| 79140 | Back Assy, NO.1 Seat, RH |
| 79140A | Back Assy, NO.1 Seat |
| 79150 | Back Assy, NO.1 Seat, LH |
| 79160 | Spring Assy, NO.1 Seat Cushion |
| 79160A | Spring Assy, NO.1 Seat Cushion, RH |
| 79169 | Rod, Rear Seat Hinge Connector |
| 79170A | Spring Assy, NO.1 Seat Cusuion, LH |
| 79175E | Pad, NO.1 Seatback, RH |
| 79180 | Spring Assy, NO.1 Seatback |
| 79180A | Spring Assy, NO.1 Seatback, RH |
| 79185 | Pad, NO.1 Seatback, LH |
| 79190A | Spring Assy, NO.1 Seatback, LH |
| 79232 | Leg, Rear NO.2 Seat, RH |
| 79242 | Leg, Rear NO.2 Seat, LH |
| 79305A | Leg Sub-assy, NO.3 Seat, RH |
| 79306 | Leg Sub Assy, NO.3 Seat, LH |
| 79320 | Cushion Assy, NO.3 Seat, RH |
| 79330 | Cushion Assy, NO.3 Seat, LH |
| 79331 | Leg, NO.3 Seat, Outer RH |
| 79335A | Pad, NO.3 Seat Cushion, RH |
| 79340 | Back Assy, NO.3 Seat, RH |
| 79341 | Leg, NO.3 Seat, Outer LH |
| 79345A | Pad, NO.3 Seat Cushion, LH |
| 79350 | Back Assy, NO.3 Seat, LH |
| 79360A | Spring Assy, NO.3 Seat Cushion, RH |
| 79370A | Spring Assy, NO.3 Seat Cushion, LH |
| 79372 | Cover, NO.3 Seat Front Bracket, RH |
| 79372A | Cover, NO.3 Seat Front Bracket, RH |
| 79374 | Cover, NO.3 Seat Leg, Rear RH |
| 79374A | Cover, NO.3 Seat Leg, Rear RH |
| 79375A | Pad, NO.3 Seatback, RH |
| 79380A | Spring Assy, NO.3 Seatback, RH |
| 79382 | Cover, NO.3 Seat Front Bracket, LH |
| 79382A | Cover, NO.3 Seat Front Bracket, LH |
| 79384 | Cover, NO.3 Seat Leg, Rear LH |
| 79384A | Cover, NO.3 Seat Leg, Rear LH |
| 79385A | Pad, NO.3 Seatback, LH |
| 79390A | Spring Assy, NO.3 Seatback, LH |
| 79910 | Cable Assy, Rear Seat Turn, NO.1 |
| 79920A | Cable Assy, Rear Seat Turn, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
