Toyota Lite/Townace V,WG
1992-01 → 1996-10 · chassis KR27,YR2#,30,CR2#,3# · catalogue 651140 · Japan
Discontinued model
Data version 1997-05
Heating & Air Conditioning - Heater Unit & Blower
21 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 87103 | Motor Sub-assy, Heater Blower, W/Fan |
| 87104R | Motor Sub-assy, Rear Heater Blower |
| 87105R | Fan Sub-assy, Rear Heater Blower |
| 87107 | Unit Sub-assy, Heater Radiator |
| 87107R | Unit Sub-assy, Rear Heater |
| 87114 | Cover, Heater |
| 87120A | Cover, Rear Heater |
| 87126 | Clamp, Heater Control |
| 87126A | Clamp, Heater Control |
| 87130 | Blower Assy, Heater, Front |
| 87130R | Blower Assy, Rear Heater |
| 87138R | Resistor, Rear Heater Blower |
| 87150 | Radiator Assy, Heater |
| 87150R | Radiator Assy, Rear Heater |
| 87187A | Wire, Blower Motor Lead |
| 87431B | Bracket, Rear Heater |
| 87660 | Servo Assy, Air Conditioner |
| 87710C | Heater Assy, Quick |
| 88650D | Amplifier Assy |
| 88655B | Switch, Water Temperature |
| 88688Y | Bracket, Cooler Stabilizer Amplifier |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
