Toyota Estima
1990-05 → 1999-12 · chassis TCR1#,2# · catalogue 652140 · Japan
Discontinued model
Data version 2000-07
Switch & Relay & Computer
103 part groups · 10 illustrations
Part groups
| PNC | Description |
|---|---|
| 28300 | Relay Assy, Starter |
| 28380A | Resister, Fuel Pump |
| 28380C | Relay Assy, Fuel Pump |
| 81980 | Flasher Assy, Turn Signal |
| 82351B | Wire,Courtesy Lamp |
| 82600F | Fuse, Fuse Block |
| 82600G | Plate, Caution(FOR FUSE) |
| 82600M | Fuse, Medium Current |
| 82650 | Breaker Assy, Wiring Circuit, NO.1 |
| 82650A | Breaker Assy, Wiring Circuit, NO.2 |
| 83320 | Gage Assy, Fuel Sender |
| 83420 | Gage Assy, Water Temperature Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 83650 | Fusee |
| 84052 | Switch Assy, Un-lock Warning |
| 84110 | Switch Assy, Light Control, NO.1 |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84162 | Switch, Front Fog Lamp |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84242 | Switch, Glove Box Lamp |
| 84261B | Junction, Slide Door Control,Male |
| 84261C | Junction, Slide Door Control,Male NO.1 |
| 84262B | Junction, Slide Door Control, Female |
| 84262C | Junction, Slide Door Control, Female, NO.1 |
| 84306 | Cable Sub-assy, Spiral |
| 84310 | Switch Assy, Turn Signal |
| 84312 | Plate, Horn Contact |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84331 | Knob, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84450 | Switch Assy, Ignition OR Starter |
| 84535A | Switch, Door Lock |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84650 | Switch Assy, Windshield Wiper |
| 84660C | Switch, Cooler |
| 84730 | Switch Assy, Heater Blower |
| 84730B | Bulb, Heater Blower Switch |
| 84730D | Cap, Heater Blower Switch Bulb |
| 84730R | Switch Assy, Heater Blower |
| 84730S | Bulb, Heater Blower Switch |
| 84732A | Switch, Rear Heater Blower |
| 84790 | Switch Assy, Rear Window Defogger |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 84810 | Switch Assy, Power Window Regulator |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84860A | Switch Assy, Sliding Roof |
| 84864 | Cover, Slide Roof Motor Switch |
| 84870A | Switch Assy, Outer Mirror |
| 84930 | Switch Assy, Door Control |
| 84930C | Bulb(FOR DOOR CONTROL SWITCH) |
| 84931B | Switch, Door Control |
| 84931D | Switch, Slide Door Control |
| 84960 | Switch Assy, Door Closer Power Supply |
| 85500 | Lighter Assy, Cigarette |
| 85513 | Cover, Cigarette Lighter |
| 85515 | Stay, Cigarette Lighter Bezel |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85535B | Cover, Power Outlet Socket, NO.1 |
| 85539 | Label, Power Outlet Notice |
| 85730 | Motor Assy, Slide Roof |
| 85910C | Relay Assy (FOR HEATER BLOWER MOTOR) |
| 85910W | Relay, Oil Level |
| 85912 | Relay, Defogger |
| 85915 | Relay, Main |
| 85916 | Relay, Light Control |
| 85916D | Relay, Fog Lamp |
| 85918A | Relay, Door Control |
| 85921 | Relay, Sliding Roof Control |
| 85930C | Relay, W/Holder |
| 85940 | Relay Assy, Windshield Wiper |
| 85940B | Relay Assy, Rear Wiper |
| 85961 | Relay, Headlamp Retainer |
| 85965 | Relay, Room Lamp Control |
| 85969 | Relay, Light Reminder |
| 85975 | Relay, Slide Door Closer |
| 85980 | Relay Assy, Door Control |
| 85985 | Relay, Key Reminder |
| 85999A | Bracket, Relay, NO.2 |
| 85999E | Bracket, Relay, NO.5 |
| 85999H | Bracket, Relay |
| 85999R | Bracket, Relay, NO.6 |
| 86530 | Relay Assy, Horn |
| 86650C | Buzzer Assy, Sedimenter Warning |
| 87989 | Relay, Mirror Control |
| 88605T | Harness Sub-assy, Air Conditioner Wiring |
| 88610M | Switch Assy, Cooler Control |
| 88610N | Switch Assy, Cooler Control |
| 88611C | Knob, Cooler Control Switch |
| 89279A | Cover, Computer |
| 89373 | Sensor, Lamp Failure Indicator |
| 89425 | Sensor, Exhaust Gas Temperature |
| 89428E | Switch, Temperature, NO.2 (FOR TRANSMISSION) |
| 89437 | Cover, Sensor |
| 89438 | Switch, Power Steering Oil Pressure |
| 89465 | Sensor, Oxygen |
| 89466 | Gasket, Oxygen Sensor |
| 89491B | Sensor, Engine Oil Level(FOR AUTO FEEDER) |
| 89615 | Sensor, Knock Control |
| 89620 | Igniter Assy |
| 89629 | Bracket, Igniter Assy |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
