Toyota Estima T/L
1999-12 → 2006-01 · chassis ACR30,40,MCR30,40 · catalogue 652150 · Japan
Discontinued model
Data version 2006-10
Spoiler & Side Mudguard
72 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 52112H | Extension, Front Bumper, RH |
| 52113F | Extension, Front Bumper, LH |
| 52161J | Extension, Rear Bumper Side, RH |
| 52162F | Extension, Rear Bumper Side, LH |
| 53821K | Protector, Front Side Panel, NO.1 RH |
| 53822G | Protector, Front Side Panel, NO.1 LH |
| 53823F | Protector, Front Side Panel, NO.2 RH |
| 53824C | Protector, Front Side Panel, NO.2 LH |
| 76621J | Nut, NO.1 |
| 76826B | Retainer, Back Door Garnish, NO.1 |
| 76851 | Cover, Front Spoiler |
| 76851A | Cover, Front Spoiler, RH |
| 76852A | Cover, Front Spoiler, LH |
| 76853A | Retainer, Front Spoiler, Upper NO.1 |
| 76853E | Retainer, Rear Spoiler, NO.1 |
| 76854A | Retainer, Front Spoiler, NO.2 |
| 76865 | Retainer, Rear Spoiler, NO.1 |
| 76871 | Spoiler, Rear |
| 76871B | Cover, Rear Spoiler |
| 76872 | Protector, Rear Spoiler, NO.1 |
| 76872A | Protector, Rear Spoiler, NO.1 |
| 76873 | Protector, Rear Spoiler, NO.2 |
| 76877A | Protector, Front Spoiler |
| 76877D | Protector, Front Spoiler Side, RH |
| 76878A | Protector, Front Spoiler Side, LH |
| 76878B | Protector, Front Spoiler |
| 76889D | Clip, Rear Spoiler, NO.2 |
| 76889E | Clip, Rear Spoiler, NO.2 |
| 76911A | Mudguard, Fender Panel, RH |
| 76912C | Mudguard, Fender Panel, LH |
| 76913 | Mudguard, Front Door, RH |
| 76914 | Mudguard, Front Door, LH |
| 76915E | Mudguard, Slide Door, RH |
| 76916E | Mudguard, Slide Door, LH |
| 76917B | Mudguard, Quarter Panel, RH |
| 76918B | Mudguard, Quarter Panel, LH |
| 76919A | Pad, Side Mudguard |
| 76919B | Pad, Side Mudguard |
| 76919C | Pad, Side Mudguard |
| 76919D | Pad, Side Mudguard |
| 76921A | Protector, Side Mudguard, NO.1 |
| 76922C | Protector, Side Mudguard, NO.2 |
| 76923 | Retainer, Side Mudguard |
| 76923A | Retainer, Side Mudguard |
| 76923C | Retainer, Side Mudguard |
| 76924C | Retainer, Side Mudguard, NO.2 |
| 76924D | Retainer, Side Mudguard, NO.2 |
| 76924J | Retainer, Front Door Side Mudguard |
| 76924L | Retainer, Slide Door Mudguard |
| 76924M | Retainer, Slide Door Mudguard |
| 76925D | Protector, Side Mudguard, RH |
| 76925E | Protector, Side Mudguard, Front RH |
| 76925F | Protector, Side Mudguard, RH |
| 76925G | Protector, Side Mudguard, RH |
| 76926D | Protector, Side Mudguard, LH |
| 76926E | Protector, Side Mudguard, Front LH |
| 76926F | Protector, Side Mudguard, LH |
| 76926G | Protector, Side Mudguard, LH |
| 76927A | Protector, Side Mudguard, Rear RH |
| 76928A | Protector, Side Mudguard, Rear LH |
| 76931 | Retainer, Side Mudguard, NO.3 |
| 76931A | Bracket, Side Mudguard, NO.1 RH |
| 76931C | Retainer, Front Door Madguard |
| 76932 | Retainer, Side Mudguard, NO.4 |
| 76932A | Bracket, Side Mudguard, NO.1 LH |
| 76932C | Retainer, Fender Panel Mudguard |
| 76932E | Retainer, Front Door Mudguard |
| 76932F | Retainer, Slide Door Mudguard |
| 76933 | Retainer, Side Mudguard, NO.5 |
| 76934 | Retainer, Side Mudguard, NO.6 |
| 76965 | Protector, Front Door Lower Mudguard |
| 76966 | Protector, Slide Door Lower Mudguard |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
