Toyota Estima

2006-01 → 2019-10 · chassis ACR5#,GSR5# · catalogue 652160 · Japan

Supported model Data version 2019-10

Seat Belt

37 part groups · 4 illustrations

PNC	Description
73023	Plate Sub-assy, Front Shoulder Belt Anchor, RH
73024	Plate Sub-assy, Front Shoulder Belt Anchor, LH
73119	Plate, Seat Belt Webbing Clip
73139B	Cover, Seat Belt Anchor
73200A	Adjuster Assy, Front Shoulder Belt Anchor
73210	Belt Assy, Front Seat Outer, RH
73219	Stopper, Tongue Plate
73220	Belt Assy, Front Seat Outer, LH
73230	Belt Assy, Front Seat Inner, RH
73233	Cover, Lap Belt Outer Anchor
73237A	Cover, Shoulder Belt Anchor
73240	Belt Assy, Front Seat Inner, LH
73310	Belt Assy, Rear Seat 3 Point Type, RH
73310A	Belt Assy, NO.1 Seat 3 Point Type, RH
73315	Cover, RR Seat Belt, Inner RH
73316	Cover, RR Seat Belt, Inner LH
73320A	Belt Assy, NO.1 Seat 3 Point Type, LH
73330D	Belt Assy, Rear NO.1 Seat Lap Type, Center RH
73345	Guide, Rear Seat Shoulder Belt, Center
73350A	Belt Assy, Rear NO.1 Seat Lap Type, Center
73360C	Belt Assy, Rear NO.1 Seat, Outer RH
73370C	Belt Assy, Rear NO.1 Seat, Outer LH
73371	Hanger, Rear Seat Shoulder Belt, RH
73371C	Hanger, Rear NO.2 Seat Shoulder Belt, RH
73372	Hanger, Rear Seat Shoulder Belt, LH
73372C	Hanger, Rear NO.2 Seat Shoulder Belt, LH
73375	Cover, Rear Seat Shoulder Belt, LH
73380C	Belt Assy, Rear NO.1 Seat, Inner RH
73390C	Belt Assy, Rear NO.1 Seat, Inner LH
73510A	Belt Assy, Rear NO.2 Seat, 3 Point Type
73530A	Belt Assy, Rear NO.2 Seat Lap Type, RH
73540C	Belt Assy, Rear NO.2 Seat Lap Type
73560	Belt Assy, Rear NO.2 Seat, Outer RH
73570	Belt Assy, Rear NO.2 Seat, Outer LH
73580	Belt Assy, Rear NO.2 Seat, Inner RH
73590	Belt Assy, Rear NO.2 Seat, Inner LH
82667B	Holder, Connector

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
