Toyota Estima Emina/Lucida
1992-01 → 1999-12 · chassis CXR1#,2#,TCR1#,2# · catalogue 653140 · Japan
Discontinued model
Data version 2000-07
Inside Trim Board
37 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 62131A | Carpet, Cowl Side, RH |
| 62132 | Clip(FOR COWL SIDE CARPET) |
| 62132A | Carpet, Cowl Side, LH |
| 62211 | Garnish, Front Pillar, RH |
| 62212 | Garnish, Front Pillar, LH |
| 62213A | Pad, Front Pillar Garnish |
| 62217G | Clip, Front Pillar Garnish |
| 62411B | Garnish, Center Pillar, Upper RH |
| 62411J | Fastener(FOR CENTER PILLAR GARNISH) |
| 62412B | Garnish, Center Pillar, Upper LH |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62416C | Board, Center Pillar Garnish, LH |
| 62431B | Garnish, Roof Side Rail, NO.1 RH |
| 62432B | Garnish, Roof Side Rail, NO.1 LH |
| 62441A | Garnish, Roof Side Rail, NO.2 RH |
| 62442A | Garnish, Roof Side Rail, NO.2 LH |
| 62471D | Garnish, Rear Pillar, Upper RH |
| 62471N | Fastener(FOR REAR PILLAR GARNISH) |
| 62472D | Garnish, Rear Pillar, Upper LH |
| 62476B | Cap, Roof Side Inner Garnish, NO.1 |
| 62597C | Pocket, Quarter Trim, NO.3 |
| 62597E | Clamp, Quarter Trim, RH |
| 62597F | Clamp, Quarter Trim, LH |
| 62613D | Clip (FOR QUARTER WHEEL HOUSE COVER) |
| 62613E | Clip (FOR QUARTER WHEEL HOUSE COVER) |
| 62613G | Cover Assy, Quarter Wheel House, RH |
| 62614F | Cover Assy, Quarter Wheel House, LH |
| 62630M | Cap(FOR QUARTER TRIM, RH) |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62638A | Garnish, Quarter Pillar, RH |
| 62638C | Fastener(FOR QUARTER PILLAR GARNISH) |
| 62639A | Garnish, Quarter Pillar, LH |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
| 62822 | Grille, Room Ventilation, LH |
| 65916A | Plate, Curtain Rail Bracket |
| 66991 | Holder, Quarter Trim Cup, RH |
| 66991A | Holder, Quarter Trim Cup, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
