Toyota Estima Emina/Lucida

1992-01 → 1999-12 · chassis CXR1#,2#,TCR1#,2# · catalogue 653140 · Japan

Discontinued model Data version 2000-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate

21 part groups · 2 illustrations

Illustrations

Figure 746136 746136 1992-01 → — Figure MBW136D MBW136D 1992-01 → —

Part groups

PNCDescription
11284A Plate, Engine Bolt Information
11289B Label, Spark Plug Notice
11291B Plate, Engine Name
11294A Label, Turbocharger Information
11296C Label, Engine Service Information
11297D Label, Engine Starting Information
13564 Label, Timing Belt Replacement Information
15369B Label, Engine Oil Notice
17700R Label, Air Cleaner Information
17791A Label, Maintenance Information
17792C Label, Engine Vacuum Hose Information
74528E Label, Power Slide Door Notice
74529 Plate, Child Proof OR Child Protector Lock Caution
74541 Plate, Tire Pressure Caution
74541E Plate, Compact Spare Tire Caution
74553A Plate, Front Seat Caution
74559A Plate, Fuel Caution
74562 Plate, Emission Control System Information
74563 Plate, Emission Control Device Identification
74571 Plate, Brake Fluid Caution
74579 Plate, Unleaded Fuel Caution
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
