Toyota Estima Hybrid

2001-05 → 2006-01 · chassis AHR10 · catalogue 656140 · Japan

Discontinued model Data version 2006-10

Battery & Battery Cable

45 part groups · 7 illustrations

PNC	Description
28800	Battery
28800A	Terminal, Battery Positive
28800D	Cover, Connector(FOR BATTERY TERMINAL)
28800J	Terminal, Battery Negative
28875	Duct, Battery Insulator, NO.1
28876	Duct, Battery Insulator, NO.2
28885	Hose, Battery Room Ventilation
28885A	Hose, Battery Room Ventilation
28895	Rubber, Battery Insulator
28899	Insulator, Battery
62931C	Duct, Quarter Vent
62932C	Duct, Quarter Vent, NO.2
62933F	Duct, Quarter Vent, Inner
62934D	Duct, Quarter Vent, Inner NO.2
62939F	Silencer, Quarter Vent
62972D	Duct, Roof Side Air, LH
74404C	Carrier Sub-assy, Battery, Upr
74405B	Cover Sub-assy, Battery
74415C	Bracket, Battery Ecu
74459A	Lid, Battery Cover, NO.2
74471C	Pad, Battery Clamp
74473B	Cushion, Battery Carrier, NO.3
74477A	Sheet, Battery Carrier
82165C	Wire, Frame, NO.2
82670J	Block Assy, Junction
82685F	Main Battery Caution Plate, NO.1
82815D	Cover, Wiring Harness Protector, NO.2
87130E	Blower Assy, Battery
89890A	Computer Assy, Battery
G3829A	Fuse, Electric Vehicle
G3830A	Plug Assy, Electric Vehicle Battery
G3833	Cover, Electric Vehicle Battery Fuse
G3834	Grip, Service Plug
G3841	Relay, System Vehicle
G3842	Resistor, System Main
G3848	Wire, System Main Relay
G3849	Plate, System Main Relay
G4283	Sensor, Battery Current
G9081A	Cable, Electric Vehicle Charger
G9242	Cable, Main Battery
G9242A	Cable, Main Battery, NO.2
G9282	Thermistor, Hybrid Battery
G9288	Label, Battery Charging Notice
G9510	Battery Assy, HV Supply
G9520B	Battery Assy, HV Recycle

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
