Toyota Cami

1999-05 → 2005-12 · chassis J100E,J102E,J122E · catalogue 661130 · Japan

Discontinued model Data version 2006-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Instrument Panel & Glove Compartment

24 part groups · 2 illustrations

Illustrations

Figure 550645B 550645B 1999-05 → — Figure 550646 550646 1999-05 → —

Part groups

PNCDescription
55045 Panel Sub-assy, Instrument Panel Finish, Lower
55301 Panel Sub-assy, Instrument
55306A Brace Sub-assy, Instrument Panel, NO.1
55355 Cushion, Instrument Panel, NO.1
55375A Bracket, Instrument Panel Lower Mounting, LH
55384 Cover, Base Switch Hole
55404C Panel Sub-assy, Instrument Cluster Finish, NO.2
55406B Panel Sub-assy, Instrument Cluster Finish, Lower Center
55441 Box, Instrument Panel
55468C Seal, Instrument Cluster Finish Panel, NO.1
55522C Cover, Radio Receiver Opening
55535C Cushion, Glove Compartment Door
55545D Cover, Instorument Panel Hole, NO.1
55546D Cover, Instrument Panel Hole, NO.2
55547E Cover, Instrument Panel Hole, NO.3
55560A Lock Assy, Glove Compartment Door
55561A Striker, Glove Compartment Door Lock
55571A Hinge, Glove Compartment Door
55581A Compartment, Glove
55620 Holder Assy, Instrument Panel Cup
55660 Register Assy, Instrument Panel, NO.2
55670A Register Assy, Instrument Panel, Center
61166A Bracket, Instrument Panel TO Cowl Side, LH
73970A Airbag Assy, Instrument Panel Passenger
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
