Toyota Hilux
2023-08 → present · chassis GUN125 · catalogue 6721D0 · Japan
Supported model
Data version 2023-09
Caution Plate
10 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 11285A | Label, Coolant System Notice |
| 11285F | Label, Coolant System Caution |
| 11293D | Label, Engine Caution |
| 11296D | Label, Engine Service Information |
| 17792D | Label, Emission Control Device Information |
| 69339C | Label, Child Protector Information |
| 74544D | Plate, Tire Carrier Caution |
| 74559B | Label, Fuel Information |
| 74751 | Label, Tire Pressure Information |
| 88723H | Label, Cooler Service Caution |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
