Toyota Stout

1979-03 → 1986-03 · chassis RK11# · catalogue 681120 · Japan

Discontinued model Data version 1986-10
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Steering Column & Shaft

21 part groups · 2 illustrations

Illustrations

Figure MC6181B MC6181B 1979-03 → — Figure MC6182C MC6182C 1979-03 → —

Part groups

PNCDescription
45201 Shaft Sub-assy, Steering Main
45201A Bearing(FOR STEERING MAIN SHAFT)
45201B Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
45201D Ring(FOR STEERING MAIN SHAFT)
45202 Shaft Sub-assy, Steering Intermediate
45205 Tube Sub-assy, Steering Column
45219 Yoke, Steering Sliding
45230 Coupling Assy, Flexible
45231C Bearing, Universal Joint Spider(FOR STEERING MAIN SHAFT)
45231D Ring, Hole Snap(FOR STEERING MAIN SHAFT)
45231K Spider Kit, Universal Joint(FOR STEERING MAIN SHAFT)
45244 Yoke, Steering Worm
45253 Cover, Steering Column Hole
45254 Shield, Steering Column Hole
45269 Retainer, Main Shaft Bearing
45272 Clamp, Steering Column, Lower
45275 Bracket, Steering Column, Upper
45281 Housing, Steering Column
45281E Plate, Safety Caution
45291A Support, Steering Column Tube
45292 Seal, Main Shaft Lower Dust
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
