Toyota Hiace Van,Wagon
1982-12 → 1987-08 · chassis YH5#,6#,71,LH5#,6#,7# · catalogue 711120 · Japan
Discontinued model
Data version 1987-12
Rear Door Panel & Glass
19 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 61648A | Reinforcement, Slide Door Window |
| 62341A | Weatherstrip, Slide Door, NO.1 |
| 62343A | Weatherstrip, Slide Door, NO.2 |
| 62687 | Carpet, Slide Door Trim, RH |
| 62688 | Carpet, Slide Door Trim, LH |
| 63379D | Washer, Slide Door Trim Setting |
| 67007 | Panel Sub-assy, Slide Door, RH |
| 67008 | Panel Sub-assy, Slide Door, LH |
| 67066 | Carpet Sub-assy, Rear Door Trim |
| 67525 | Cover, Slide Door Panel, Lower |
| 67528A | Packing, Slide Door Lower Cover |
| 67607 | Board Sub-assy, Slide Door Trim, RH |
| 67607A | Clip(FOR SLIDE DOOR TRIM BOARD) |
| 67608 | Board Sub-assy, Slide Door Trim, LH |
| 67631C | Pocket, Rear Door Trim Board |
| 67657A | Clip, Slide Door Trim Carpet |
| 67708 | Ornament Sub-assy, Rear Door Trim |
| 67772B | Cap, Rear Door Trim Retainer |
| 67852A | Cover, Slide Door Service Hole, NO.2 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
