Toyota Hiace Van,Wagon
1982-12 → 1987-08 · chassis YH5#,6#,71,LH5#,6#,7# · catalogue 711120 · Japan
Discontinued model
Data version 1987-12
Speaker
24 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 86160 | Speaker Assy, Front NO.1 |
| 86160A | Speaker Set, Front |
| 86160C | Speaker Set, Rear |
| 86160E | Speaker Set, Stereo Component |
| 86160Q | Speaker Assy, Roof |
| 86160S | Speaker Set |
| 86160T | Speaker Assy, Rear Header |
| 86160U | Speaker Assy, Quarter Side |
| 86202 | Wire, Speaker, NO.1 |
| 86202A | Wire, Speaker, NO.2 |
| 86202E | Wire, Speaker, NO.5 |
| 86219 | Bracket, Stereo Component Speaker, NO.1 |
| 86219A | Bracket, Stereo Component Speaker, NO.2 |
| 86219B | Bracket, Stereo Component Speaker, NO.3 |
| 86219C | Bracket, Stereo Component Speaker, NO.4 |
| 86219D | Bracket, Speaker, Rear NO.1 |
| 86219E | Bracket, Speaker, Rear NO.2 |
| 86238 | Wire, Speaker, NO.7 |
| 86238A | Wire, Speaker, NO.8 |
| 86262A | Cover, Speaker, Front |
| 86262B | Cover, Speaker, Rear |
| 86264B | Grille, Speaker, Rear |
| 86264D | Grille, Speaker, Roof |
| 86378A | Spacer, Speaker |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
