Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Exhaust Pipe
32 part groups · 12 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 17400 | Converter Assy, W/Catalyst |
| 17400B | Retainer, Exhaust Pipe |
| 17400D | Bracket, Catalytic Converter Support |
| 17402 | Pipe Sub-assy, Exhaust, Front NO.2 |
| 17410 | Pipe Assy, Exhaust, Front |
| 17410A | Nut, Exhaust Pipe Set Stud Bolt |
| 17410B | Gasket, Exhaust Pipe |
| 17420 | Pipe Assy, Exhaust, Center |
| 17420X | Gasket, Exhaust Pipe, Center |
| 17430 | Pipe Assy, Exhaust, Tail |
| 17430S | Bracket, Exhaust Tailpipe (FOR REAR) |
| 17448 | Baffle, Tailpipe |
| 17451 | Gasket, Exhaust Pipe |
| 17504 | Bracket Sub-assy, Catalytic Converter |
| 17505E | Support Sub-assy, Catalytic Converter |
| 17508 | Support Sub-assy, Exhaust Pipe, NO.3 |
| 17561B | Support, Exhaust Pipe, NO.1 |
| 17563A | Support, Exhaust Pipe, NO.3 |
| 17564 | Support,Exhaust Pipe, NO.4 |
| 17565A | Support, Exhaust Pipe, NO.4 |
| 17571 | Bracket, Exhaust Pipe Support, NO.1 |
| 17573A | Bracket, Exhaust Pipe Support, NO.3 |
| 17575 | Bracket, Exhaust Pipe Support, NO.5 |
| 17578A | Clamp, Muffler |
| 17581A | Damper, Exhaust Pipe |
| 17586 | Bracket, Heat Insulator, NO.1 |
| 17594 | Protector, Exhaust Pipe, NO.2 |
| 17595 | Protector, Exhaust Pipe, Lower NO.3 |
| 18435 | Protector, Catalytic Converter |
| 18435A | Protector, Monolithic Converter |
| 18448 | Bracket, Converter Protector, Center |
| 18491 | Flange, Thermosensor Inlet |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
