Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Rear Floor Panel & Rear Floor Member
158 part groups · 18 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 51058 | Bracket Sub-assy, Lower Control Link, RH |
| 51059 | Bracket Sub-assy, Lower Control Link, LH |
| 51265A | Bracket, Rear Shock Absorber, RH |
| 51266A | Bracket, Rear Shock Absorber, LH |
| 51267A | Reinforcement, Rear Shock Absorber Mounting, RH |
| 51268 | Reinforcement, Rear Shock Absorber Mounting, LH |
| 51341B | Gusset, Frame NO.4 Crossmember, RH |
| 51341C | Gusset, Crossmember, NO.4 Upper |
| 51351C | Gusset, Crossmember, NO.5 RH |
| 51352A | Gusset, Crossmember, NO.5 LH |
| 51354 | Plate, Rear Shock Absorber Member |
| 51527 | Bracket, Lateral Rod Support, Rear NO.1 |
| 51537B | Bracket, Lateral Rod Support, Front |
| 51538B | Bracket, Lateral Rod Support, Rear |
| 51569A | Guard, Propeller Shaft |
| 51682 | Bracket, Flexible Hose, NO.2 |
| 51715B | Spacer, Step Panel Cover |
| 52295A | Brace, Rear Suspension Member, RH |
| 53761C | Bracket, Battery Clamp |
| 57023 | Member Sub-assy, Rear Side, RH |
| 57024 | Member Sub-assy, Rear Side, LH |
| 57071A | Hanger Sub-assy, Rear Spring, Front, RH |
| 57072A | Hanger Sub-assy, Rear Spring, Front, LH |
| 57075 | Bracket Sub-assy, Upper Control Link, RH |
| 57076 | Bracket Sub-assy, Upper Control Link, LH |
| 57078 | Member Sub-assy, Rear Floor Rear Cross, Outer |
| 57079 | Member Sub-assy, Rear Floor Rear Cross, Inner |
| 57307B | Outrigger Sub-assy, NO.4 RH |
| 57308B | Outrigger Sub-assy, NO.4 LH |
| 57311 | Outrigger, NO.1 RH |
| 57314 | Outrigger, NO.2 LH |
| 57321B | Outrigger, NO.5, RH |
| 57322B | Outrigger, NO.5, LH |
| 57361A | Cover, NO.2 Outerigger Hole |
| 57362A | Packing, NO.2 Outrigger Hole Cover |
| 57413 | Rail, Floor Side, Center RH |
| 57414 | Rail, Floor Side, Center LH |
| 57415 | Rail, Floor Side, Rear RH |
| 57416 | Rail, Floor Side, Rear LH |
| 57419A | Plate, Rear Seat Lock |
| 57426A | Plate, Rear Step, Front LH |
| 57428B | Plate, Rear Step, Rear LH |
| 57515 | Bracket, Parking Brake, RH |
| 57516 | Bracket Sub-assy, Parking Brake, LH |
| 57617A | Retainer, Exhaust Pipe Bracket |
| 57637A | Reinforcement, Rear Floor Side, RH |
| 57652C | Member, Rear Floor Cross, NO.1 |
| 57653D | Member, Rear Floor Cross, NO.2 |
| 57654B | Member, Rear Floor Cross, NO.3 |
| 57655A | Member, Rear Floor Cross, NO.4 |
| 57656C | Member, Rear Floor Croos, NO.5 |
| 57657B | Member, Rear Floor Cross, NO.6 |
| 57657C | Crossmember, Rear Floor, NO.6 |
| 57658 | Member, Rear Floor Cross, NO.7 |
| 57659C | Member, Rear Floor Cross, NO.8 |
| 57665A | Reinforcement, Rear Floor Crossmember, NO.2 |
| 57666A | Reinforcement, Rear Floor Crossmember, NO.3 |
| 57667A | Reinforcement, Rear Floor Crossmember, NO.4 |
| 57668B | Reinforcement, Rear Floor Crossmember, NO.5 |
| 57671C | Brace, Rear Floor NO.1 Crossmember, RH |
| 57688A | Reinforcement, Rear Floor Crossmember |
| 57689 | Reinforcement, Rear Floor Crossmember, NO.2 |
| 57691 | Brace, Rear Floor NO.2 Crossmember, Inner RH |
| 57692A | Brace, Rear Floor NO.2 Crossmember, Inner LH |
| 57693B | Brace, Rear Floor NO.6 Crossmember |
| 57695A | Extension, Rear Floor Crossmember Rear Side, RH |
| 57696A | Extension, Rear Floor Crossmember Rear Side, LH |
| 57699A | Retainer, Fuel Tank Set Band |
| 57749A | Reinforcement, Lateral Rod Bracket, NO.2 |
| 57751 | Support, Rear Suspension Spring, Outer RH |
| 57756 | Plate, Rear Floor NO.2 Crossmember |
| 57767 | Retainer, Fuel Tank Band |
| 57771 | Plate, Rear Spring, RH |
| 57773 | Reinforcement, Rear Spring |
| 57774A | Reinforcement, Rear Spring, LH |
| 57779 | Retainer, Upper Control Link, Upper |
| 57799 | Gusset, Rear Floor Crossmember |
| 57815 | Reinforcement, Belt Anchor, NO.1 |
| 57817 | Reinforcement, Belt Anchor, NO.2 |
| 57817A | Reinforcement, Belt Anchor, NO.2 |
| 57817B | Reinforcement, Belt Anchor, NO.2 |
| 57829 | Reinforcement, Seat Leg |
| 57871 | Patch, Rear NO.1 Seat Leg, Rear NO.1 |
| 58022A | Reinforcement Sub-assy, Header Panel |
| 58106 | Bracket Sub-assy, Brake Tube Connector, NO.2 |
| 58194 | Retainer, Engine Cover Hinge |
| 58207C | Cover Sub-assy, Transmission Service Hole |
| 58209B | Cover Sub-assy, Battery Service Hole |
| 58221A | Panel, Header |
| 58223F | Reinforcement, Header Panel, NO.2 |
| 58224F | Reinforcement, Header Panel, NO.3 |
| 58228D | Patch, Header Panel, LH |
| 58248F | Reinforcement, Header Panel, Upper |
| 58266B | Bracket, Fuel Tube Clamp |
| 58273C | Reinforcement, Belt Anchor TO Center Floor |
| 58275C | Bracket, Wire Harness Protector |
| 58278D | Protector, Fuel Tank, Upper |
| 58303B | Step Sub-assy, Rear Floor, RH |
| 58304B | Step Sub-assy, Rear Floor, LH |
| 58307F | Cover Sub-assy, Rear Floor Step |
| 58307H | Bracket Sub-assy, Brake Tube Conn, NO.1 |
| 58311 | Pan, Rear Floor |
| 58315B | Panel, Rear Floor, Front |
| 58316E | Retainer, Rear Seat Set |
| 58318C | Bracket, Rear Floor Crossmember |
| 58329F | Cover, Rear Floor Service Hole, NO.2 |
| 58346A | Bracket, Rear Floor Heat Insulator, NO.2 |
| 58348D | Cover, Rear Absorber Service Hole, RH |
| 58351A | Bracket, Spare Wheel Carrier |
| 58352A | Bracket, Rear Floor Stay |
| 58352B | Reinforcement, Rear Floor Panel, LH |
| 58364B | Bracket, Fuel Tank Support |
| 58445D | Lock, Battery Service Hole Cover |
| 58446C | Protector, Battery |
| 58449B | Packing, Battery Service Hole Cover |
| 58450A | Packing, Battery Service Hole Cover |
| 58451B | Cover, Air Cleaner Service Hole |
| 58453A | Shield, Air Cleaner Service Hole |
| 58458C | Knob, Battery Service Hole Cover |
| 58465B | Packing, Transmission Service Hole Cover |
| 58466E | Silencer, Transmission Service Hole Cover, NO.1 |
| 58475B | Packing, Inspection Hole Cover |
| 58553B | Reinforcement, Rear Seat Belt, NO.3 |
| 58555B | Reinforcement, Rear Seat Belt, NO.5 |
| 58797 | Bracket, Jack Clamp Band |
| 58888B | Base, Cooling Box |
| 58893A | Retainer, Rear Seat NO.2, Rear RH |
| 58894C | Retainer, Rear Seat NO.2, Rear LH |
| 59209A | Cover Sub-assy, Inspection Hole |
| 59306 | Retainer Sub-assy, Rear Seat |
| 59361A | Retainer, Rear Seat, NO.1 |
| 59361B | Retainer, Rear Seat, NO.1 A |
| 59362A | Retainer, Rear Seat, NO.1 B |
| 59362B | Retainer, Rear Seat, NO.1 B |
| 59362D | Retainer, Rear Seat, NO.1 B |
| 59363 | Retainer, Rear Seat, NO.1 C |
| 59363B | Retainer, Rear Seat, NO.1 C |
| 59364 | Retainer, Rear Seat, NO.1 D |
| 59364A | Retainer, Rear Seat, NO.1 D |
| 59365A | Reteiner, Rear Seat, NO.2 |
| 59366 | Retainer, Rear Seat, NO.2 |
| 59367 | Retainer, Rear Seat, NO.2 C |
| 59367A | Retainer, Rear Seat, NO.4 |
| 59368 | Retainer, Rear Seat, NO.2 D |
| 59371 | Retainer, Rear Seat, NO.3 |
| 59374 | Retainer, Seat Belt Anchor, NO.3 |
| 59375 | Retainer, Rear Seat, NO.4 |
| 61753F | Anchor, Rear Seat Belt, Lwr |
| 61951B | Retainer, Seat Anchor, NO.1 |
| 65557 | Retainer, Rope Hook |
| 65557B | Retainer, Rope Hook |
| 66311 | Hook, Rope |
| 67132A | Reinforcement, Slide Door Down Stop, Lwr |
| 74732A | Bracket, Tool Bag Set Band |
| 77652D | Stopper, Fuel Tank |
| C3134 | Reinforce, Rear Floor Rear Corner, RH |
| C3281 | Spacer, Floor Board |
| C9121 | Base, Power Lift Arm Guide Rail |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
