Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Side Member
91 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58741B | Protector, Quarter Panel, RH |
| 58741C | Protector, Quarter Panel, RH |
| 58742B | Protector, Quarter Panel, LH |
| 58742C | Protector, Quarter Panel, LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61027A | Pillar Sub-assy, Front Body, Outer RH |
| 61028A | Pillar Sub-assy, Front Body, Outer LH |
| 61031B | Extension Sub-assy, Quarter Panel, RH |
| 61032B | Extension Sub-assy, Quarter Panel, LH |
| 61033A | Reinforce Sub-assy, Back Door Opening Side |
| 61037 | Reinforce Sub-assy, Front Body Pillar, Center |
| 61051A | Panel Sub-assy, Quarter Lock, Inner RH |
| 61052A | Panel Sub-assy, Quarter Lock, Inner LH |
| 61057A | Extension Sub-assy, Quarter Lock Pillar |
| 61058A | Extension Sub-assy, Quarter Lock Pillar, LH |
| 61197A | Cover, Front Pillar, RH |
| 61198A | Cover, Front Pillar, LH |
| 61211 | Rail, Roof Side, Outer RH |
| 61212 | Rail, Roof Side, Outer LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61233A | Rail, Roof Side, Inner NO.2 RH |
| 61234A | Rail, Roof Side, Inner NO.2 LH |
| 61246 | Reinforcement, Roof Side Rail, Outer LH |
| 61261 | Channel, Roof Drip, RH |
| 61262 | Channel, Roof Drip, LH |
| 61301C | Pillar Sub-assy, Center Body, Outer RH |
| 61302C | Pillar Sub-assy, Center Body, Outer LH |
| 61307 | Pillar Sub-assy, Center Body, Inner RH |
| 61308 | Pillar Sub-assy, Center Body, Inner LH |
| 61339B | Seal, Center Body Pillar, Inner NO.1 |
| 61345B | Pillar, Center Body, Inner Lower RH |
| 61391 | Spacer, Center Body Pillar, Inner |
| 61411D | Panel, Fender, Outer RH |
| 61412D | Panel, Fender, Outer LH |
| 61413B | Panel, Front Step, RH |
| 61414B | Panel, Front Step, LH |
| 61415A | Panel, Front Step, Under, RH |
| 61416A | Panel, Front Step Under, LH |
| 61423A | Panel, Fender, Inner Lower RH |
| 61424A | Panel, Fender, Inner Lower LH |
| 61451 | Panel, Rocker, Outer RH |
| 61452A | Panel, Rocker Outer, LH |
| 61511 | Pillar, Quarter Lock, RH |
| 61512 | Pillar, Quarter Lock, LH |
| 61606 | Frame Sub-assy, Back Door Opening Side, RH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61613C | Panel Sub-assy, Quarter, Inner Rear RH |
| 61614C | Panel Sub-assy, Quarter, Inner Rear LH |
| 61617B | Panel, Quarter Inner, Lower RH |
| 61618B | Panel, Quarter, Inner Lower LH |
| 61625E | Extension, Quarter Panel, Inner Rear RH |
| 61626E | Extension, Quarter Panel, Inner Rear LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61633A | Panel, Quarter Wheel House, Inner RH |
| 61634A | Panel, Quarter Wheel House, Inner LH |
| 61637D | Reinforcement, Quarter, Inner RH |
| 61638D | Reinforcement, Quarter, Inner LH |
| 61667A | Spacer Quarter Panel, NO.1 |
| 61706A | Frame Sub-assy, Back Door Opening Side, LH |
| 61719B | Bracket, Roof Side, Inner |
| 61739B | Reinforcement, Extension Quarter Inner Panel |
| 61741A | Reinforcement, Back Door Opening, Upper RH |
| 61742A | Reinforcement, Back Door Opening, Upper LH |
| 61744A | Reinforcement, Back Door Opening Side, LH |
| 61768B | Reinforce, Belt Anchor TO Roof Side, Inner Rear RH |
| 61769B | Reinforce, Belt Anchor TO Roof Side, Inner Rear LH |
| 61771B | Frame, Back Door Opening Upper Corner, RH |
| 61772B | Frame, Back Door Opening Upper Corner, LH |
| 61785D | Extension, Back Door Opening Side, RH |
| 61786A | Extension, Back Door Opening Side, LH |
| 61917A | Base, Quarter Inner Bed Holder, RH |
| 61918A | Base, Quarter Inner Bed Holder, LH |
| 62137A | Reinforce, Side Window Panel |
| 62417F | Pad, Center Pillar Garnish, RH |
| 62428B | Cover, Center Pillar, RH |
| 62429 | Cover, Center Pillar Service Hole |
| 62429B | Cover, Center Pillar Service Hole |
| 62621D | Pad, Quarter Wheel House, Inner Front RH |
| 62657B | Cover, Quarter Panel Inner, LH |
| 63155B | Retainer, Roof Panel Support |
| 67813A | Sheet, Quarter Panel Silencer, RH |
| 67841D | Cover, Quarter Service Hole, RH |
| 67842D | Cover, Quarter Service Hole, LH |
| 67898C | Seal, Slide Door, Lower NO.2 |
| 76607 | Mudguard Sub-assy, Quarter Panel, Rear RH |
| 76608 | Mudguard Sub-assy, Quarter Panel, Rear LH |
| 81399 | Bracket, Step Lamp |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
