Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Inside Trim Board
73 part groups · 21 illustrations
Illustrations
Part groups
| PNC | Description |
|---|---|
| 56153A | Moulding, Front Window, Inner Center |
| 61729B | Bracket, Roof Side Rail, LH |
| 62211 | Garnish, Front Pillar, RH |
| 62212 | Garnish, Front Pillar, LH |
| 62311B | Weatherstrip, Front Door Opening Trim, RH |
| 62312B | Weatherstrip, Front Door Opening Trim, LH |
| 62313D | Trim, Front Door Opening, RH |
| 62314D | Trim, Front Door Opening, LH |
| 62401A | Clip (FOR CENTER PILLAR GARNISH PANEL, UPPER) |
| 62411B | Garnish, Center Pillar, Upper RH |
| 62411J | Fastener(FOR CENTER PILLAR GARNISH) |
| 62412B | Garnish, Center Pillar, Upper LH |
| 62413A | Garnish, Center Pillar, Lower RH |
| 62413C | Clip (FOR CENTER LOWER GARNISH) |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62422 | Cover, Center Pillar Garnish, LH |
| 62424F | Cover, Center Pillar Garnish, Lower LH |
| 62425 | Cover, Center Pillar Garnish |
| 62431B | Garnish, Roof Side Rail, NO.1 RH |
| 62432B | Garnish, Roof Side Rail, NO.1 LH |
| 62441A | Garnish, Roof Side Rail, NO.2 RH |
| 62442A | Garnish, Roof Side Rail, NO.2 LH |
| 62465 | Pad, Quarter Lock Pillar, RH |
| 62466 | Pad, Quarter Lock Pillar, LH |
| 62471E | Garnish, Roof Side, Inner Upper RH |
| 62471J | Clip (FOR ROOF SIDE GARNISH) |
| 62471N | Fastener(FOR REAR PILLAR GARNISH) |
| 62472E | Garnish, Roof Side, Inner Upper LH |
| 62476A | Cap, Roof Side Inner Garnish, RH |
| 62476B | Cap, Roof Side Inner Garnish, NO.1 |
| 62477A | Cap, Roof Side Inner Garnish, LH |
| 62481B | Base, Roof Side Inner Garnish, RH |
| 62482B | Base, Roof Side Inner Garnish, LH |
| 62501C | Cover Sub-assy, Quarter Trim, RH |
| 62507A | Panel Sub-assy, Quarter Trim, RH |
| 62508A | Box Sub-assy, Side Trim |
| 62508C | Panel Sub-assy, Quarter Trim, LH |
| 62510P | Panel Assy, Quarter Trim, Front RH |
| 62511B | Clip (FOR QUARTER INSIDE TRIM BOARD) |
| 62520C | Clip, Quarter Trim Board, NO.1 |
| 62520D | Clip, Quarter Trim Board, NO.2 |
| 62536B | Garnish, Pillar NO.2, RH |
| 62571A | Garnish, Roof Side, Inner Lower RH |
| 62572A | Garnish, Roof Side Inner Lower LH |
| 62573A | Garnish, Quarter Lock Pillar, RH |
| 62574A | Garnish, Quarter Lock Pillar, LH |
| 62580B | Board Assy, Side Heater Cover, RH |
| 62581F | Clip (FOR QUARTER PILLAR GARNISH) |
| 62581G | Cover, Quarter Pillar, RH |
| 62582G | Cover, Quarter Pillar, LH |
| 62587D | Retainer, Side Heater Cover |
| 62588B | Clip (FOR SIDE HEATER COVER) |
| 62629 | Board, Side Trim, Lower NO.1 A |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62632D | Board, Quarter Trim, Rear LH |
| 62633C | Clip (FOR QUARTER TRIM GARNISH) |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
| 64383B | Grille, Rear Speaker, RH |
| 64384B | Grille, Rear Speaker, LH |
| 64707C | Knob, Jack Cover |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 65923H | Hook, Curtain |
| 65923J | Hook, Curtain |
| 66990A | Holder Assy, Cup |
| 66995A | Retainer, Cup Holder |
| 67687B | Garnish, Back Window |
| 73223A | Cover, Seat Belt Retractor |
| 75023 | Lid Sub-assy, Tool Box, RH |
| 75024 | Lid Sub-assy, Tool Box, LH |
| 85575B | Bracket, Auto Curtain Rail, NO.3 RH |
| 85576B | Bracket, Auto Curtain Rail, NO.3 LH |
| 85577A | Bracket,Auto Curtain Rail,NO.4 RH |
| 85578A | Bracket,Auto Curtain Rail,NO.4 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
