Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Electronic Controled Diesel (ECD)
13 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 85915B | Relay, Main (FOR DIESEL TURBO) |
| 85915F | Relay, Spill Valve |
| 89421C | Sensor, Turbo Pressure (FOR DIESEL TURBO) |
| 89422C | Sensor, Diesel Engine Water Temperature |
| 89424A | Sensor, Inlet Air Temperature (FOR DIESEL TURBO) |
| 89428B | Switch, Temperature |
| 89452B | Sensor, Throttle Position |
| 89454 | Sensor, Fuel Temperature |
| 89455A | Sensor, Egr Valve Position |
| 89661A | Computer, Engine Control |
| 89667A | Bracket, Engine Control Computer, NO.1 |
| 89668A | Bracket, Engine Control Computer, NO.2 |
| 89669B | Bracket, Engine Control Computer, NO.3 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
