Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Speaker
27 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 86150 | Speaker Assy, W/Box, NO.1 |
| 86160 | Speaker Assy, Front NO.1 |
| 86160B | Speaker Assy, Rear |
| 86160N | Speaker Assy, Stereo Component, Rear |
| 86160P | Speaker Assy, Front NO.2 |
| 86160Q | Speaker Assy, Roof |
| 86160Y | Speaker Assy, Rear NO.2 |
| 86161 | Bracket, Speaker, Front NO.1 |
| 86161D | Bracket, Speaker Mounting, NO.1 |
| 86163 | Bracket, Speaker, NO.2 |
| 86202 | Wire, Speaker, NO.1 |
| 86202A | Wire, Speaker, NO.2 |
| 86202C | Wire, Speaker, NO.3 |
| 86219A | Bracket, Stereo Component Speaker, NO.2 |
| 86219B | Bracket, Stereo Component Speaker, NO.3 |
| 86219D | Bracket, Speaker, Rear NO.1 |
| 86219H | Bracket, Speaker, Roof, NO.1 |
| 86219J | Bracket, Speaker, Roof, NO.2 |
| 86219S | Bracket, Stereo Speaker, RH |
| 86229 | Bracket, Stereo Speaker, LH |
| 86264 | Grille, Speaker, Front |
| 86264B | Grille, Speaker, Rear |
| 86264D | Grille, Speaker, Roof |
| 86269A | Grille, Speaker |
| 86269B | Grille, Speaker |
| 86279 | Grille, Speaker, LH |
| 86816 | Speaker Interphone |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
