Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Camera & Rear Monitor Display
30 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 55054A | Stopper Sub-assy, Glove Compartment Door |
| 55561C | Striker, Glove Compartment Door Lock |
| 82817Q | Protector, Wiring Harness, NO.15 |
| 84992A | Switch, Television |
| 84992B | Bulb |
| 86010A | Tuner Assy, Television |
| 86011J | Filter, Noise |
| 86017 | Parts Set, Video |
| 86028 | Bracket Sub-assy, Television |
| 86061 | Holder Sub-assy, Video |
| 86108 | Leg Sub-assy, Audio Rack, NO.2 |
| 86117A | Bracket, Television Display, A |
| 86119A | Wire, Television Switch |
| 86170B | Switch & Volume Assy, Television |
| 86172 | Receiver, Television Remote Control |
| 86191A | Terminal, Video(VIDEO ADAPTER) |
| 86251A | Wiring, Amplifier |
| 86264F | Cover, Tape Player |
| 86291 | Bracket, Television |
| 86292 | Cover, Television Set |
| 86293 | Bracket, Television, NO.2 |
| 86295 | Base, Television |
| 86680A | Display Assy, Television |
| 86680B | Controlle, Television |
| 86680C | Controlle, Television Antenna |
| 86683 | Relay, Television |
| 86685 | Light, Television |
| 86690A | Video Deck Assy |
| 86691 | Holder, Video |
| 86699 | Stopper, Video Holder |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
