Toyota Hiace/Regiusace
1989-08 → 2005-01 · chassis KZH1##,LH1##,RZH1##,TRH1## · catalogue 711140 · Japan
Discontinued model
Data version 2005-07
Telephone & Mayday
37 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 75895E | Tape, Moulding, NO.1 |
| 86070 | Mobilephone & Accessory Assy |
| 86070A | Mobilephone & Accessory Assy (HANDSET) |
| 86090 | Telephone Assy |
| 86162A | Relay, Speaker |
| 86282B | Bracket, Microphone |
| 86702 | Bracket Set, Telephone |
| 86710 | Computer Assy, Telephone |
| 86712 | Wire, Telephone |
| 86714 | Controller, Telephone |
| 86719 | Bracket, Telephone |
| 86720 | Mobilephone Assy |
| 86720A | Mobilephone Assy |
| 86723 | Wire, Mobilephone |
| 86723A | Wire, Mobilephone |
| 86725 | Battery, Mobilephone |
| 86726 | Cover, Mobilephone |
| 86726A | Cover, Mobilephone, NO.2 |
| 86726B | Cover, Mobilephone, NO.3 |
| 86726C | Cover, Mobilephone |
| 86729 | Bracket, Mobilephone |
| 86730 | Microphone Assy, Telephone |
| 86742 | Cover, Transceiver |
| 86750 | Switch Assy, Telephone |
| 86760 | Antenna Assy, Telephone |
| 86771B | Charger, Portablephone Battery |
| 86771C | Computer, Portablephone |
| 86773 | Wire, Portablephone |
| 86774 | Charger, Portablephone AC |
| 86775A | Handset, Portablephone |
| 86776 | Battery, Portablephone-s |
| 86776A | Cover, Telephone Wire |
| 86777 | Battery, Mayday |
| 86779 | Strap, Portablephone |
| 86810 | Computer Assy, Interphone |
| 86814 | Switch, Interphone |
| 86815 | Microphone, Interphone |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
