Toyota Hiace/Regiusace
2013-12 → present · chassis KDH2##,TRH2##,GDH2## · catalogue 711160 · Japan
Supported model
Data version 2020-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 15104 — Strainer Sub-assy, Oil | ||||
| 15104-11220 |
Strainer Sub-assy, Oil
2017-12 → 2020-05
ended
|
1GDFTV GDH20#,211,22# | ¥6,400 | |
| 15104-11220 |
Strainer Sub-assy, Oil
2017-12 → 2020-06
ended
|
1GDFTV GDH221,226 IV6 | ¥6,400 | |
| 15104-11221 |
Strainer Sub-assy, Oil
2020-06 → 2021-07
ended
|
1GDFTV GDH201,223 IV5 | ¥4,780 | |
| 15104-11221 |
Strainer Sub-assy, Oil
2020-06 → 2023-12
ended
|
1GDFTV CBU GDH201 V2 +9 | ¥4,780 | |
| 15104-11221 |
Strainer Sub-assy, Oil
2020-06 → —
|
1GDFTV 5D;1GDFTV ,211,22# GDH20# +19 | ¥4,780 | |
| 15104-67060 |
Strainer Sub-assy, Oil
2013-12 → 2017-11
ended
|
1KDFTV KDH20#,211,22# | ¥6,000 | |
| 15104-75111 |
Strainer Sub-assy, Oil
2013-12 → 2015-01
ended
|
1TRFE TRH200 V2 HRF +3 | ¥6,300 | |
| 15104-75111 |
Strainer Sub-assy, Oil
2013-12 → 2014-11
ended
|
1TRFE TRH200 SRF 5F;1TRFE +4 | ¥6,300 | |
| 15104-75220 |
Strainer Sub-assy, Oil
2014-11 → 2021-07
ended
|
1TRFE TRH200 SRF 5F;1TRFE +4 | ¥4,360 | |
| 15104-75220 |
Strainer Sub-assy, Oil
2015-01 → 2021-07
ended
|
1TRFE TRH200 V2 HRF +1 | ¥4,360 | |
| 15104-75220 |
Strainer Sub-assy, Oil
2014-11 → 2022-12
ended
|
1TRFE,2TRFE TRH200,21#,22# 6FC | ¥4,360 | |
| 15104-75221 |
Strainer Sub-assy, Oil
2023-01 → 2023-12
ended
|
1TRFE TRH200 V2 HRF +7 | ¥3,960 | |
| 15104-75221 |
Strainer Sub-assy, Oil
2023-01 → —
|
1TRFE S) TRH200 6FC;1TRFE,2TRFE +13 | ¥3,960 | |
| 15104E — Bolt, Stud(FOR OIL STRAINER) | ||||
| 90116-06140 |
Bolt, Stud(FOR OIL STRAINER)
2013-12 → 2017-11
ended
|
1KDFTV KDH20#,211,22# | ¥100 | |
| 90126-08052 note |
Bolt, Stud(FOR OIL STRAINER)
2013-12 → 2014-11
ended
|
1TRFE TRH200 SRF 5F;1TRFE +4 | ¥80 | |
| 90126-08052 note |
Bolt, Stud(FOR OIL STRAINER)
2013-12 → 2015-01
ended
|
1TRFE TRH200 V2 HRF +3 | ¥80 | |
| 15149 — Gasket, Oil Strainer Flange | ||||
| 15149-11120 |
Gasket, Oil Strainer Flange
2017-12 → 2021-07
ended
|
1GDFTV GDH201,223 IV5 | ¥270 | |
| 15149-11120 |
Gasket, Oil Strainer Flange
2017-12 → 2023-12
ended
|
1GDFTV CBU GDH201 V2 +9 | ¥270 | |
| 15149-11120 |
Gasket, Oil Strainer Flange
2017-12 → —
|
1GDFTV 5D;1GDFTV ,211,22# GDH20# +19 | ¥270 | |
| 15149-67010 |
Gasket, Oil Strainer Flange
2013-12 → 2017-11
ended
|
1KDFTV KDH20#,211,22# | ¥270 | |
| 15193 — Gasket, Oil Pump | ||||
| 15193-67011 |
Gasket, Oil Pump
2013-12 → 2017-11
ended
|
1KDFTV KDH20#,211,22# | ¥330 | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
