Toyota Granace
2019-12 → present · chassis GDH303 · catalogue 711170 · Japan
Supported model
Data version 2019-12
Instrument Panel & Glove Compartment
69 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 52161V | Piece, Instrument Panel |
| 55011A | Garnish Sub-assy, Instrument Panel, NO.1 |
| 55012A | Garnish Sub-assy, Instrument Panel, NO.2 |
| 55044C | Panel Sub-assy, Instrument Panel Finish |
| 55047A | Cluster Sub-assy, Meter Hood, RH |
| 55048A | Cluster Sub-assy, Meter Hood, LH |
| 55061 | Register Sub-assy, Instrument Panel, NO.1 |
| 55062 | Register Sub-assy, Instrument Panel, N0.2 |
| 55301 | Panel Sub-assy, Instrument |
| 55306A | Brace Sub-assy, Instrument Panel, NO.1 |
| 55307C | Brace Sub-assy, Instrument Panel, NO.2 |
| 55308D | Box Sub-assy, Instrument Panel, Center |
| 55312 | Panel, Instrument, Lower |
| 55312A | Clip, Instrument Panel |
| 55314A | Panel, Instrument, Lower Center |
| 55315C | Patch, Instrument Side, Upper RH |
| 55316A | Patch, Instrument Side, Upper LH |
| 55317A | Panel, Instrument Side, RH |
| 55318C | Panel, Instrument Side, LH |
| 55320 | Panel Assy, Instrument, Lower NO.2 |
| 55328 | Pin, Instrument Panel, NO.1 |
| 55330B | Reinforcement Assy, Instrument Panel |
| 55349A | Cushion, Instrument Panel |
| 55355 | Cushion, Instrument Panel, NO.1 |
| 55357B | Cushion, Instrument Panel, NO.3 |
| 55359A | Protector, Instrument Panel, NO.2 |
| 55374A | Bracket, Instrument Panel Lower Mounting, RH |
| 55375A | Bracket, Instrument Panel Lower Mounting, LH |
| 5538E | Bracket, Electrical Parts Mounting |
| 55403 | Hood Sub-assy, Meter |
| 55404E | Panel Sub-assy, Instrument Cluster Finish, Upr |
| 55405B | Panel Sub-assy, Instrument Cluster Finish, Center |
| 55410C | Panel Assy, Instrument Cluster Finish |
| 55413D | Panel, Instrument Cluster Finish, Center Lower |
| 55432D | Panel, Instrument Panel Finish, Lower NO.1 |
| 55433B | Panel, Instrument Panel Finish, Lower NO.2 |
| 55434B | Panel, Instrument Panel Finish, Lower Center |
| 55437A | Retainer, Instrument Panel Finish Panel, NO.1 |
| 55438A | Retainer, Instrument Panel Finish Panel, NO.2 |
| 55443D | Knob, Instrument Panel Box Door |
| 55446A | Base, Switch Hole, NO.1 |
| 55447C | Base, Switch Hole, NO.2 |
| 55465B | Knob, Instrument Panel Box Lock |
| 55476A | Garnish, Instrument Cluster Finish Panel, NO.3 |
| 55524H | Cover, Switch Base Hole |
| 55539 | Cover, Spare Switch Hole |
| 55539D | Cover, Spare Switch Hole |
| 55548A | Cover, Instrument Panel Hole |
| 55550 | Door Assy, Glove Compartment |
| 55557A | Cushion, Glove Compartment Door Check |
| 55608 | Cover Sub-assy, Instrument Panel Under, NO.3 |
| 55620 | Holder Assy, Instrument Panel Cup |
| 55631A | Stopper, Instrument Panel Under Tray, NO.1 |
| 55632B | Support, Instrument Panel Under Tray, NO.2 |
| 55634 | Support, Instrument Panel Under Tray, NO.3 |
| 55641 | Cover, Instrument Panel Under, NO.1 |
| 55642 | Cover, Instrument Panel Under, NO.2 |
| 55661A | Bezel, Instrument Panel Register |
| 55662A | Bezel, Instrument Panel Resister, NO.2 |
| 55670 | Register Assy, Instrument Panel, NO.3 |
| 55680A | Register Assy, Instrument Panel, NO.4 |
| 55961B | Nozzle, Side Defroster, NO.1 |
| 55962D | Nozzle, Side Defroster, NO.2 |
| 55981 | Garnish, Defroster Nozzle, NO.1 |
| 58533C | Cover, Floor Carpet, Center RH |
| 58534E | Cover, Floor Carpet, Center LH |
| 62199 | Holder, Fusee |
| 73900 | Airbag Assy, Instrument Panel, Lower NO.1 |
| 73960A | Airbag Assy, Instrument Panel Passenger W/O Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
