Toyota Granace
2019-12 → present · chassis GDH303 · catalogue 711170 · Japan
Supported model
Data version 2019-12
Seat Belt
34 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 73015A | Bracket Sub-assy, Belt Outer Anchor, RH |
| 73023 | Plate Sub-assy, Front Shoulder Belt Anchor, RH |
| 73024 | Plate Sub-assy, Front Shoulder Belt Anchor, LH |
| 73119 | Plate, Seat Belt Webbing Clip |
| 73178C | Cap, Seat Belt Anchor Cover |
| 73200A | Adjuster Assy, Front Shoulder Belt Anchor |
| 73210 | Belt Assy, Front Seat Outer, RH |
| 73214 | Plate, Front Seat Belt Anchor |
| 73219 | Stopper, Tongue Plate |
| 73220 | Belt Assy, Front Seat Outer, LH |
| 73230 | Belt Assy, Front Seat Inner, RH |
| 73233 | Cover, Lap Belt Outer Anchor |
| 73233E | Cover, Rear Outer Seat Belt |
| 73240 | Belt Assy, Front Seat Inner, LH |
| 73310A | Belt Assy, NO.1 Seat 3 Point Type, RH |
| 73310E | Belt Assy, NO.2 Seat 3 Point Type, RH |
| 73320A | Belt Assy, NO.1 Seat 3 Point Type, LH |
| 73320D | Belt Assy, NO.2 Seat 3 Point Type, LH |
| 73373B | Cover, Rear NO.1 Seat Shoulder Belt |
| 73373C | Cover, Rear NO.2 Seat Shoulder Belt |
| 73375X | Cover, Rear Seat Shoulder Belt, LH NO.1 |
| 73375Y | Cover, Rear Seat Shoulder Belt, LH NO.2 |
| 73380C | Belt Assy, Rear NO.1 Seat, Inner RH |
| 73380D | Belt Assy, Rear Seat, Inner |
| 73380U | Belt Assy, Rear NO.1 Seat, Inner LH |
| 73380V | Belt Assy, Rear NO.2 Seat, Inner RH |
| 73380W | Belt Assy, Rear NO.2 Seat, Inner LH |
| 73390A | Belt Assy, Rear Seat, Inner |
| 73560A | Belt Assy, NO.3 Seat, Outer RH |
| 73570A | Belt Assy, NO.3 Seat, Outer LH |
| 82193C | Wire, Rear NO.1 Seat, RH |
| 82193D | Wire, Rear NO.2 Seat, RH |
| 82194A | Wire, Rear NO.1 Seat, LH |
| 82194B | Wire, Rear NO.2 Seat, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
