Toyota Regius/Touring Hiace
1997-04 → 2002-05 · chassis KCH4#,LXH4#,RCH4# · catalogue 712110 · Japan
Discontinued model
Data version 2002-10
Side Window
78 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 62229 | Packing, Side Window |
| 62229A | Packing, Side Window, NO.2 |
| 62229C | Packing, Side Window |
| 62249 | Plate, Side Window, RH |
| 62249A | Plate, Side Window, LH |
| 62249E | Plate, Side Window |
| 62279A | Spacer, Side Window Frame |
| 62279D | Spacer, Side Window Frame, LH |
| 62279E | Spacer, Side Window Frame |
| 62279H | Spacer, Side Window Frame |
| 62391A | Stopper, Side Window, NO.1 Front RH |
| 62391B | Stopper, Side Window, NO.1 Front LH |
| 62703E | Frame Sub-assy, Side Rear Window, RH |
| 62707A | Frame Sub-assy, Side Front Window, RH |
| 62708F | Frame Sub-assy, Side Front Window, LH |
| 62711K | Glass, Quarter Window, Front RH |
| 62712K | Glass, Side Window, Front RH |
| 62713K | Glass, Side Window, Rear RH |
| 62715F | Glass, Side Rear Window, RH |
| 62719A | Packing, Side Front Window, Upper |
| 62719C | Packing, Side Front Window |
| 62719E | Packing, Side Front Window |
| 62721A | Hinge, Side Front Window, Upper |
| 62723B | Hinge, Side Rear Window, Upper |
| 62723C | Hinge, Side Rear Window, Upper |
| 62724C | Stop, Side Front Window Glass, RH |
| 62724D | Stop, Side Front Window Glass, LH |
| 62724E | Stop, Side Rear Window Glass, RH |
| 62724F | Stop, Side Rear Window Glass, LH |
| 62725C | Run, Side Front Window Glass |
| 62725D | Run, Side Front Window Glass |
| 62727A | Run, Side Rear Window Glass, RH |
| 62729C | Pad, Rear Window Center Sash, RH |
| 62729D | Pad, Rear Window Center Sash, LH |
| 62729F | Pad, Rear Window Center Sash, LH |
| 62733B | Glass, Side Rear Window, Rear RH |
| 62735 | Retainer, Quarter Window Hinge |
| 62735B | Retainer, Side Front Window Hinge, RH |
| 62735C | Retainer, Side Front Window Hinge, LH |
| 62736 | Glass, Slide Door Window, Rear LH |
| 62741D | Weatherstrip, Side Front Window |
| 62742A | Glass, Side Rear Window, Front LH |
| 62742D | Weatherstrip, Side Front Window, LH |
| 62743C | Weatherstrip, Side Rear Window |
| 62744B | Weatherstrip, Side Rear Window, LH |
| 62745A | Weatherstrip, Side Window Glass, RH |
| 62746B | Packing, Quarter Window, RH |
| 62746D | Packing, Quarter Window, LH |
| 62749B | Seal, Side Window Frame |
| 62749D | Seal, Side Window Flame |
| 62755E | Packing, Side Front Window, Lower |
| 62755H | Packing, Side Front Window, Lower |
| 62755K | Packing, Side Front Window, Lower |
| 62762K | Glass, Side Door Window, Front LH |
| 62785C | Spacer, Quarter Window Glass |
| 62793B | Retainer, Side Window Lock, RH |
| 62793C | Retainer, Side Window Lock, LH |
| 62794B | Retainer, Side Window Lock |
| 62796A | Moulding, Side Rear Window |
| 62798B | Moulding, Side Window, Front NO.1 RH |
| 62798C | Moulding, Side Window, Front NO.3 LH |
| 62881A | Bracket, Quarter Window Guard |
| 62897 | Tube, Side Window Guard |
| 62910 | Lock Assy, Quarter OR Side Window, RH |
| 62910K | Lock Assy, Quarter Window, RH |
| 62918B | Spacer, Side Window Frame |
| 62918C | Stay, Side Rear Window Lock |
| 62919 | Stay, Slide Door Window Lock |
| 62920A | Lock Assy, Side Front Window, LH |
| 63273M | Retainer, Roof Window Hinge, RH |
| 63273N | Retainer, Roof Window Hinge, LH |
| 63273Q | Retainer, Quarter Window Hinge |
| 67045A | Frame Sub-assy, Side Front Window, Center RH |
| 67046 | Frame Sub-assy, Side Front Window, Center LH |
| 67455A | Hinge, Slide Door Window, Upper |
| 67465 | Hinge, Slide Door Window, Lower |
| 67479A | Cover, Slide Door Window Lock |
| 67479B | Cover, Slide Door Window Lock |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
