Toyota Regius/Touring Hiace
1997-04 → 2002-05 · chassis KCH4#,LXH4#,RCH4# · catalogue 712110 · Japan
Discontinued model
Data version 2002-10
Inside Trim Board
67 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 55523A | Cover, Heater Control Opening |
| 55560E | Lock Assy, Quarter Trim Cover |
| 62111A | Trim Sub-assy, Cowl Side, RH |
| 62111B | Clip(FOR COWL SIDE TRIM) |
| 62111E | Retainer, Cowl Side Trim |
| 62112A | Trim Sub-assy, Cowl Side, LH |
| 62211 | Garnish, Front Pillar, RH |
| 62212 | Garnish, Front Pillar, LH |
| 62401A | Clip (FOR CENTER PILLAR GARNISH PANEL, UPPER) |
| 62411B | Garnish, Center Pillar, Upper RH |
| 62411D | Plug, Hole (FOR CENTER PILLAR GARNISH) |
| 62412B | Garnish, Center Pillar, Upper LH |
| 62413A | Garnish, Center Pillar, Lower RH |
| 62414A | Garnish, Center Pillar, Lower LH |
| 62417C | Pad, Center Pillar, RH |
| 62418C | Pad, Center Pillar, LH |
| 62424F | Cover, Center Pillar Garnish, Lower LH |
| 62427 | Bracket, Center Pillar Garnish, RH |
| 62431B | Garnish, Roof Side Rail, NO.1 RH |
| 62432B | Garnish, Roof Side Rail, NO.1 LH |
| 62441A | Garnish, Roof Side Rail, NO.2 RH |
| 62442A | Garnish, Roof Side Rail, NO.2 LH |
| 62471A | Garnish, Roof Side, Inner RH |
| 62471N | Fastener(FOR REAR PILLAR GARNISH) |
| 62472A | Garnish, Roof Side, Inner LH |
| 62476A | Cap, Roof Side Inner Garnish, RH |
| 62476B | Cap, Roof Side Inner Garnish, NO.1 |
| 62476C | Cap, Roof Side Inner Garnish, NO.1 |
| 62476D | Cap, Quarter Trim Board |
| 62481B | Base, Roof Side Inner Garnish, RH |
| 62482B | Base, Roof Side Inner Garnish, LH |
| 62501C | Cover Sub-assy, Quarter Trim, RH |
| 62508A | Box Sub-assy, Side Trim |
| 62510P | Panel Assy, Quarter Trim, Front RH |
| 62533A | Bracket, Quarter Trim Clamp |
| 62571A | Garnish, Roof Side, Inner Lower RH |
| 62572A | Garnish, Roof Side Inner Lower LH |
| 62573A | Garnish, Quarter Lock Pillar, RH |
| 62573C | Fastener(FOR CENTER PILLAR GARNISH) |
| 62574A | Garnish, Quarter Lock Pillar, LH |
| 62595C | Board, Side Heater Cover, RH |
| 62597B | Clamp, Quarter Trim |
| 62629A | Label, Quarter Trim |
| 62630K | Clip(FOR QUARTER TRIM REAR PANEL) |
| 62630P | Panel Assy, Quarter Trim, Rear RH |
| 62630Q | Clip (FOR QUARTER TRIM) |
| 62630R | Cap (FOR QUARTER TRIM) |
| 62630T | Cap |
| 62638A | Garnish, Quarter Pillar, RH |
| 62639A | Garnish, Quarter Pillar, LH |
| 62640P | Panel Assy, Quarter Trim, Rear LH |
| 64707C | Knob, Jack Cover |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 64740A | Panel Assy, Deck Trim Side, LH |
| 66991 | Holder, Quarter Trim Cup, RH |
| 66991A | Holder, Quarter Trim Cup, LH |
| 67687B | Garnish, Back Window |
| 74543G | Label, Rear NO.3 Seat Caution |
| 85567 | End, Auto Curtain Rail, NO.2 |
| 85571B | Bracket, Auto Curtain Rail, NO.1 RH |
| 85572B | Bracket, Auto Curtain Rail, NO.1 LH |
| 85573B | Bracket, Auto Curtain Rail, NO.2 |
| 85574B | Bracket, Auto Curtain Rail, NO.2 LH |
| 85575B | Bracket, Auto Curtain Rail, NO.3 RH |
| 85576B | Bracket, Auto Curtain Rail, NO.3 LH |
| 85577A | Bracket,Auto Curtain Rail,NO.4 RH |
| 85578A | Bracket,Auto Curtain Rail,NO.4 LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
