Toyota Regius/Touring Hiace
1997-04 → 2002-05 · chassis KCH4#,LXH4#,RCH4# · catalogue 712110 · Japan
Discontinued model
Data version 2002-10
Overdrive & Electronic Controlled Transmission
14 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 33485B | Plate, Transmission Wire |
| 35478A | Gasket, Shift Control Solenoid |
| 35517 | Plate, Transmission Wire Lock |
| 82125B | Wire, Transmission |
| 84220A | Switch Assy, Transmission Position Indicator |
| 84720 | Switch Assy, Pattern Select |
| 84720C | Bulb(FOR PATTERN SELECT SWITCH) |
| 84720D | Cap, Pattern Select Switch |
| 85420 | Solenoid Assy, Transmission |
| 89411C | Sensor, Speed |
| 89414 | Rotor, Sensor |
| 89428D | Switch, Temperature, NO.2 |
| 89429A | Sensor, Temperature |
| 89530A | Computer Assy, Transmission Control |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
